MS50/TS50/TM50, Technical Data
71
7Technical Data
7.1 Angle Measurement
Accuracy
Characteristics Absolute, continuous, diametric.
7.2 Distance Measurement with Reflectors
Range For TS50/TM50 - R1000:
For MS50 - R2000:
Type std. dev. Hz, V, ISO 17123-3 Display least count
["] [mgon] ["] [mgon]
TM50 R1000/
TM50 I R1000
0.5 0.15 0.1 0.01
1 0.30 0.1 0.01
TS50 I R1000 0.5 0.15 0.1 0.01
MS50 R2000 1 0.30 0.1 0.01
Reflector Range A Range B Range C
[m] [ft] [m] [ft] [m] [ft]
Standard prism (GPR1,
GPH1P)
1800 6000 3000 10000 3500 12000
360° prism (GRZ4, GRZ122) 800 2600 1500 5000 2000 7000
360° Mini prism (GRZ101) 450 1500 800 2600 1000 3300
Mini prism (GMP101) 800 2600 1200 4000 2000 7000
Reflector tape (GZM31)
60 mm x 60 mm
150 500 250 800 250 800
Machine Automation power
prism (MPR122)

For Machine Control
purposes only!
800 2600 1500 5000 2000 7000
Shortest measuring distance: 1.5 m
Reflector Range A Range B Range C
[m] [ft] [m] [ft] [m] [ft]
Standard prism (GPR1,
GPH1P)
2200 7300 7500 24600 >10000 >32800
360° prism (GRZ4, GRZ122) 1200 3900 2250 7500 3000 10500
360° Mini prism (GRZ101) 670 2250 1200 3900 1500 4950
Mini prism (GMP101) 1200 3900 1800 6000 3000 10500
Reflector tape (GZM31)
60 mm x 60 mm
220 750 375 1200 370 1200
Machine Automation power
prism (MPR122)

For Machine Control
purposes only!
1200 3900 2250 7500 3000 10500
Shortest measuring distance: 1.5 m
