18
Chapter 3 Frame Mortise & Tenon Jig User Guide
THE FMT PRO JIG
3-40 Always disconnect the power source from the router when
fitting bits, or making adjustments.
Before connecting the router to the power source, make sure the
bit revolves freely through the Sub-Base bit hole, and table and
clamp plate bit openings in all extreme guide pin positions and
preset bit depths.
3-41 Make sure the router collet does not contact the FMT Pro
Sub-Base at full plunge cuts. Set the router plunge stop rod as
necessary to prevent this
➀
.
1
3-42 Do not tilt the router on the jig. 3-43 Keep the router flat on the jig assembly.
3-44 Always raise the plunge router mechanism before removing
the router assembly from the jig.
3-45 Never, never, use a non-plunge fixed base router on the
FMT Pro.
