Leigh FMT PRO - Guide and Bit Selection

57
Appendix IFrame Mortise & Tenon Jig User Guide
JOINT SPECIFICATIONS, GUIDE & BIT SELECTION
A1-11 Maximum Mortise Board Width and Thickness
for Mortising to Center
Width up to 4
5
⁄8"[115mm]
➀
.
Thickness up to 4"[100mm]
➁
.
Note: See 6-21 mounting instructions for these pieces.
2
1
A1-12 Maximum Width Mortise Board
for Mortising to Center
Width from 4
5
⁄8"[115mm]
up to 6
1
⁄2"[165mm]
➀
See 6-22 for special instructions.
■
Guide and Bit Selection
1
Guide and Bit Selection
Use the following charts to select appropriate guide and bit combinations.
➔
