Frame Mortise & Tenon Jig User Guide
39
Chapter 5
MULTIPLE JOINTS
5-46 Remember, mortises are routed the opposite way around to
their matching tenon, e.g. in this illustration the single tenon is to
the right
➀
, single mortise to the left
➁
. Keeping the reference faces
together on the finished joint will ensure that the mortises and tenons
will align
➂
. It’s much easier to clamp square section workpieces so do
not do any shaping of workpieces until after the joints are routed
➃
.
■
2
1
4
3
5-44 Release the table clamp. With the table to the right, against
the
stop, put the small block between the rear
stop
and its post
➀
. You must always use the same limit stop for all
other third tenons and mortises. Using a guard to avoid routing,
into the other two tenons
➁
, rout the rest of the third tenon
➂
.
1
1
3
2
5-45 m Mortises Triple mortises are routed the opposite way
around. If the single tenon is to the right
➀
, the single mortise
must be to the left
➁
, and vice-versa, using the same block on
the same side of the stop post
➂
.
3
2
1
