Appendix III Frame Mortise & Tenon Jig User Guide
CUSTOMER SUPPORT
QUANTITY
PART NO. PER JIG PART DESCRIPTION
311 2 1/2" x 3" Compression Springs
371 4 1/4" x 7/8" x .031" Nylon Washers
371R 2 9/32" x 7/8" x .016" Nylon Washers
501 3 8-32 x 3/8" Square Socket No.2 Robertson
5100 2 Sub-Base Fence Rods 8.453" long, 7mm dia.
5130 2 M6x14mm Hex Socket Button Hd Cap Screws (for Festool)
6001 1 LH End Housing
6006 1 RH End Housing
6011 1 Top Extrusion
6015 1 Bottom Extrusion
6020 3 10 x 1-1/4" Self tapping No.2 Robertson Oval Hd Screws
6030 6 1/4 - 20 Hex Nuts (for Quadrant Knobs & Jig Hold-down)
6040 2 Limit Stop Posts
6050 1 Angle Indicator Decal
6055 1 UHMW Strip Long
6056 3 UHMW Strip Short
6060 4 1/4-20 x 1" Flat Hd Machine Screws (Jig Hold-down)
6101 1 Clamp Plate
6106 1 Vacuum Box
6107 1 Vacuum Box Swivel
6108 1 Vacuum Hose Adaptor – Small
6109 1 Vacuum Hose Adaptor – Large
6110 1 LH Quadrant
6115 1 RH Quadrant
6120 2 Quadrant Bushings
6125 3 Hex Socket Flat Point Set Screws 1/4-28 x 3/8"
6130 2 Outrigger Bars
6135 1 Quadrant Angle Indicator
6140 8 6-32 x 3/8" Hex Socket Button Hd Screws
6145 3 10 x 1-1/4" Self Tapping No.2 Robertson SQ Drive Pan Hd Screws
6155 5 Hex Socket Flat Point Set Screw 1/4-28 X 5/8"
6166A Side Stop Fence Assembly complete
6027 1 Washer - 3mm
6166 1 Side Stop Fence Body
6171 1 Side Stop Squaring Block
6191 1 T-Bolt
6199 2 Washers
6410 2 10-24 x 3/8" Hex Socket Button Hd Cap Screw
9530 1 Lever
6410 4 10-24 x 3/8" Hex Socket Button Hd Cap Screws (for attaching vacuum box)
6195 8 8-32 x 3/4" Flat Hd Machine Screws (for Outrigger & Low Shim Spacers)
6196 4 8-32 Hex Nuts (for Outriggers)
6200 2 Clamp T-Bolts 3/8"-16
6205 3 3/8" x 3/4" x .062" Nylon Flat Washers
6210 2 3/8-16 Clamp T-Bolt Brass nuts
6220 2 Clamp Arm
6225 2 Clamp Arm Heel Pads
6230 2 Clamp Arm Toe Pads
6235 2 Clamp Swivel Pads
6240 2 Clamp Lifters
6245 2 Clamp Lifter Springs
7025 2 Quadrant Knobs
7145 8 10 x 1-1/4" Self Tapping No.2 Robertson SQ Drive Pan Hd Screws
7225R 1 Top Extrusion Stop Post Screw
801-375 2 Cam-Action Speed Clamps
802-375 2 Speed Clamp Step Washers
