Appendix III Frame Mortise & Tenon Jig User Guide
CUSTOMER SUPPORT
QUANTITY
PART NO. PER JIG PART DESCRIPTION
6300 1 Intermediate Plate Assembly c/w pressed-in Pins
6310 4 pairs Wedge Blocks
6315 4 Wedge Block Compression Springs
6320 4 Limit Stops
6325 4 Limit Stop Nuts
6330 4 10-24 x 3/8" Hex Socket Nyloc Flat Hd Machine Screws
6335 2 UHMW Glides
6400 1 Table Clamp Rod
6405 1 Table Clamp Handle
6406 1 Clamp Handle Sleeve - Lower
6407 1 Clamp Handle Sleeve - Upper
6410 6 10-24 x 3/8" Hex Socket Button Hd Cap Screw
6415 2 "Pull Down" Clamp Block
6420 1 LH "Push-Up" Clamp Sleeve
6425 1 RH "Push-Up" Clamp Sleeve
6430 2 Hex Socket Hd Shoulder Screws 1/4" x 3/4" (10-24)
6435 2 1/4" Flat Washers SS
6440 2 1/4" Fiber Washers
6445 1 5/32" x 1" Spring Pin
6455 1 Snap Ring 3/8" x .035" thick
6500 1 Table Plate Assembly c/w Decals & Teflon Pads
6505 1 Sight
6510 1 LH Sight Rail
6515 1 RH Sight Rail
6530 2 Sight Rail Spring Detents
6535 1 RH Guide Pin "Track"
6540 4 Teflon Decal Pads
6550 1 Guide Latch
6555 1 Guide Latch Spring
6600 1 Sub-Base Plate Assembly c/w Decals & Teflon Pads
6605 1 LH Teflon Pad
6611 2 Teflon Discs
6615 2 Guide Pins
6620 2 Guide Pin Bushes
6625 2 Guide Pin Knobs
6626 2 Guide Pin Height Washers
6630 2 O-rings 4.5mm I.D. x 1mm
6633 2 O-rings 7.0mm I.D. x 1mm
6635 4 Sub-Base U-posts ( includes screws 6155 and 6195)
6640 4 "Low" Shim-Spacers
6645 4 "High" Shim-Spacers
6655 4 8-32 x 1" No.2 Sq Dr Flat Hd Machine Screws (for High-Shims)
6660 1 Sub-Base Handle
6665 1 "INCH" Mandrel (1/4" and 1/2")
6670 1 "METRIC" Mandrel (8mm and 12mm)
