X75 Quick Start Guide 3
X75SD/X75HD Multiple Path Converters and Frame Synchronizers Quick Start Guide
Checking the Packing List
Before unpacking your product, read the “Unpacking/Shipping Information” on page v
of your X75SD/X75HD Multiple Path Converters and Frame Synchronizers Installation
and Operation Manual.
Standard Items
The following items are included with every X75 system:
• One X75 Multiple Path Converter and Frame Synchronizer
• One AC power cable (773-254 or 773-505)
• Two rear support brackets (741-983A) and corresponding hardware
• Two cable relief support brackets (164-000306-00) and one corresponding cable
relief bar (164-000305-00)
These items are only included with X75-AV and X75-LCAV systems:
• Two 2x7 analog audio terminal blocks (134-000228-00) (this item may be
pre-installed on your unit)
• Eight-channel audio module with X75OPTCAB-8-C breakout cable
OR
• Sixteen-channel audio module with X75OPTCAB-16-C and X75OPTCAB-8-C
coax breakout cables
Optional Items
You may have additional items included in your shipment if you have ordered any of the
available options or upgrades. Some options may include the following:
• X75OPTCAB-MULTI breakout cable
• X75OPTCAB-DVI DVI-D digital video cable
• X75OPTCAB-8-CX combination BNC/XLR audio breakout cable
• X75OPTCAB-16-CX combination BNC/XLR audio breakout cable
• X75OPTCAB-8-X XLR audio breakout cable
• X75OPTCAB-16-X XLR audio breakout cable
• X75OPT-ASL audio limiter software key for X75OPT-AS-8/16 digital audio
synchronizers
• X75OPT-A3D high performance 3D-adaptive decoder, composite, component
Betacam, and S-video input
• X75OPT-PQM video module
• X75OPT-NR digital noise reduction and digital bandwidth filtering software key
• X75-RCP remote control panel
• X75OPT-PS power supply kit for optional, redundant power supply (typically
factory installed, although can be field-upgraded)
• X75SPR-KIT spare parts kit
