LELY WELGER AP 830 User Manual

LELY WELGER AP 530 · AP 630 · AP 730 · AP 830 83
5.5 Specification
AP 530 AP 630 AP 730 AP 830 P 23
Baling chamber (
height x width) [cm] 36 x 48 36 x 49 -
Bale length [cm] 50 to 120 < 80
Twine tying with high-grade twine
a) sisal
b) plastic
a) 200,150 or 125 m/kg
b) 400 (only AP530 / 630), 320 or 250 m/kg
-
Wire tying with high-grade wire
Tensile strength
Coil size
Non-galvanized, annealed, oiled wire ;
1.8 / 2.0 mm thickness,
35 – 49 kg/mm² ; elongation min. 12%
outside: 336 mm ; inside: 208 mm
-
Pick-up width [cm] 173 180 205 -
Speed of tractor PTO shaft [rpm] 540 -
Hydraulic oil pressure max.[bar] 180
Connection for control P23 12V / 25A
Permissible total weight [kg] see data plate at the machine 220 kg
Data are for approximate specifications and are not binding.
Versions can vary.
1)
Observe deviating national road traffic law!
