WELGER RP 202 • RP 220 • RP 302 • RP 320 25
5.1.2. Setting the twine brake
Basic set up
Spring length at the twine brake (fig. 29)
BALERCONTROL E
(fig. 26)
BALERCONTROL III
(fig. 27)
Twine A
(shown as continuous line )
39 mm 33 mm
Twine B
(shown as dashed line - - - - - - )
37 mm 28 mm
The twines brakes [1] (fig. 26 and fig. 27) must hold the twines
as taut as possible for the twine to be tight around the bales.
Note:
The permitted thread tension is exceeded when the twine
breaks in the vicinity of the guide rollers [8] (fig. 28).
fig. 29
