LEM d400 - Technical Specifications

12
10. Technical specifications
Components
High
Low
1" compression driver with titanium diaphragm
12" woofer with neodimuim magnet
Construction
Cabinet
Protection
Transport
Flyning hardware
Reinforced polypropilene
Metal grid
Aluminium handle
4 M10 flying points
Weight kg 19,2
Dimensions mm (WxHxD) 400x620x375
Inputs / Outputs
sensitivity
impedance
+4 dB (nominal) / -40dB (max)
20 kOhms (balanced)
A/D converter bit 24
D/A converter
bit
Dynamic range
Sampling Rate
24
100 dB
48 kHz
Crossover
Type
Frequency
Slope
Bessel, Butterworth or Linkwitz-Riley
Variable from 15.6 Hz to 16 kHz
6, 12, 18, 24, or 48dB per octave
EQ
Number
Type
Gain
Bandwidth
Freq
25 parametric bands
Peak, 6dB Lo-Shelf, 12dB Lo-Shelf, 6dB Hi-Shelf, 12dB Lo-Shelf, Notch
+/-15dB, variable in 0.5dB steps
0.05 to 3.00 octaves, variable in 0.05 steps
15.6 Hz to 16 kHz
Alignment delay max delay 189 ms
Plugins Noise Gate, Anti-feedback, Multiband compressor
Protections
Independent peak limiter for each output
Long-term power protection
LFC - Low Frequency Control
Output power
EIA (1kHz, THD 1%)
Alti
Bassi
100W, AB class
300W, H class
Distortion % <0.02
Controls
Volume
PRESETS selector
Connectors
1 x COMBO (LINE + MIC input)
1 x XLR-M (link)
Power supply socket
Power supply see label on the apparatus
Frequency response Hz 45 - 20000 (-10dB)
Sensitivity MAX SPL Continuous 123 dB
Dispersion ° 100x60
d400 - TECHNICAL SPECIFICATIONS
LOUDSPEAKER SPECIFICATIONS
PROCESSOR/AMPLIFIER SPECIFICATIONS
SYSTEM SPECIFICATIONS
