030124 ** 1u 50V 20% Vert Electrolytic Bipolar Capacitor
030005 ** 1u 50V 20% Vert Electrolytic Capacitor
021024 ** 100n 63V 10% MKT Polyester Capacitor
021008 ** 4n7 63V 10% MKT Polyester Capacitor
011244 ** 4n7 16V 10% Cer. Cap. Smd CL2 X7R 0603
011218 ** 33p 16V 10% Cer. Cap. Smd CL2 X7R 0603
010595 ** 100n 50V -20+80% Ceramic Cap. Multilayer
010462 ** 1n 50V 10% CL2 Ceramic Capacitor
010426 ** 470p 50V 10% CL2 Ceramic Capacitor
010413 ** 390p 50V 10% CL2 Ceramic Capacitor
010405 ** 220p 500V 10% CL2 Ceramic Capacitor
010335 ** 100p 500V 10% CL2 Ceramic Capacitor
010304 ** 47p 50V 10% CL2 Ceramic Capacitor
080821 * Ptc 100° PTH9L04BD222TS2F330 Murata
Power Devices
100060 * 7815 +15V 1A Voltage Regulator
100059 * 7805 +5V 1A Voltage Regulator
100049 * 7915 -15V 1A Voltage Regulator
090920 * MJE802 TO126 Npn Darl Transistor
090919 * MJE15031 TO220 Pnp Transistor
090918 * MJE15030 TO220 Npn Transistor
090863 * TIP36C TO218 Pnp Transistor
090862 * TIP35C TO218 Npn Transistor
SKK090014 * 2SA1943 TO264 Pnp Transistor
SKK090013 * 2SC5200 TO264 Npn Transistor
080609 * GBPC2502W 25A 200V Rectifi er Diode Bridge
X300
Accessories
277407 Owner’s Manual
Cabinet Assembly
841338 40cm Blue/Black 0.75mm² Faston/Faston Dual Wire
841337 40cm Brown/Black 1.50mm² Faston/Faston Dual Wire
768297 4 Ohm Crossover & Protection Board (Pcb#313131) This part is replaced entirely only.
768302 8 Ohm Crossover & Protection Board (Pcb#313131) This part is replaced entirely only.
667780 Handle
667767 Speaker Protection Grid
347423 Rear Speaker Chassis
347419 Stand Fixing Knob
347418 Ø29x20mm Rubber Foot
347417 Compression Driver Support (Throat)
347415 Front Speaker Chassis
229048 1” 8ohm Compression Driver
229051 * 1” 8ohm Diaphgram for 229048 Driver
227087 12” 4ohm Woofer
227098 12” 8ohm Woofer
210288 Ø3mm Rubber Sealer (specify mt)
210217 Black Sealer (specify mt)
180835 “X300” Adhesive Label
150298 100x2.5mm Nylon Cable Tie
120976 M5x20 Screw/M10x27 Nut-M4 Int.thread Spacer
120975 M10 Suspension Point (M14 external turned)
120606 M14x8 Nut
120525 5mm Black Spring Washer
120477 28x15x2.5 Washer
120461 5.3x10x1 Black Washer
120387 WL5x50tc Black Screw
120364 WL3.5x12tt Black Screw
120341 WL4x20tt Black Screw
120336 WL4x25tt Black Screw
120157 M5x50tt Screw
120147 M4x10tt Black Screw
120083 M6x25te Black Screw
727655 4 Ohm Input Panel Assembly
778165 * Single Speakon Cables Assembly
141200 ** Speakon Socket (NL4MP Neutrik)
667782 * 4 Ohm Input Panel
120581 * M3 Black Self-Locking Nut
120451 * 3.2x7x0.5 Black Washer
120030 * M3x12tsp Black Screw
727656 8 Ohm Input Panel Assembly
778178 * Dual Speakon Cables Assembly
141200 ** Speakon Socket (NL4MP Neutrik)
667783 * 8 Ohm Input Panel
120581 * M3 Black Self-Locking Nut
120451 * 3.2x7x0.5 Black Washer
120030 * M3x12tsp Black Screw
Note:
- All dimensions are in mm unless otherwise specifi ed.
- The screw description is defi ned as follows:
type of screw + diameter + X + length + type of head
where type of screw is one of these:
M = Metric thread
B = Self-tapping screw for metal
WL = Self-tapping screw for wood
and type of head is one of these:
tc = cylinder Phillips head
ts = fl ared Phillips head
tt = rounded Phillips head
te = hexagonal nut head
tsp = fl at fl ared Phillips head
tce = cylinder Allen hexagonal head
tspe = fl at fl ared Allen hexagonal head
- The washer description is defi ned as follow:
hole diameter + X + external diameter + X + thick
- Each spare part is single quantity unless otherwise specifi ed.
- Asterisk prefi x explanation:
Omitted = First level spare part.
One asterisk = Second level, part of previous listed fi rst level part.
Two asterisk = Third level, part of previous listed second level part.
Three asterisk = ............
- Any request for not above mentioned part must encompass specifi c description including:
1) Model name,
2) Section name,
3) Module code,
4) Reference name,
5) Quantity number.
