DCBM 100 Series
N° 99.W1.99.000.0
01March23/Version 1
DC ENERGY METER
3
Specifications
•
Time source to set product’s time must be
provided by the customer. Product must be
time synchronized to operate.
•
Product’s Ethernet interface mustn’t be
exposed to a public network; network must be
private and secured.
•
To ensure proper operation, product’s logbook
completion must be checked periodically;
the maximum number of entries is 204 000;
product’s operation stops if logbook is full.
•
The meter must be installed inside an
enclosure IP51 (indoor) or IP54 (outdoor)
according to EN 50470:2007.
Accuracy notices according to examination
certificate
•
The direct current meters may only be used
for billing purposes in a charging device and
only for measuring the energy supplied to
the vehicle.
•
For the device types DCBM_
N0D_0800_0000, DCBM_N0D_0810_0000,
for which the compensation factor can be
selected via the Ethernet interface, the
interface must be sealed or a calibrated
remote station must be directly connected
and secured by means of seals. At the end
of the transaction, this remote station must
compare the cable ID specified in the data
tuple signed by the DC meter with the cable
ID originally transferred to the DC meter. If
this comparison is valid then the data tuple
can be used.
Compliance with
•
EN 50470-1: 2006
•
EN 50470-3: 2006
•
IEC 62052-31: 2015
•
IEC 62052-31:2014
•
Rated insulation voltage: 1000 V DC
•
Overvoltage category: II
•
Pollution degree: II
•
Insulation type: Reinforced according to
IEC 60664-1
•
Impulse withstand voltage insulation barrier :
4.77kV
•
Impulse withstand voltage between I1/I2 and I3/I4 :
6.4kV
•
Humidity max: 95 % HR
•
All plastics materials are UL94 recognized
•
Storage temperature: −40 °C / +80 °C
•
Operating temperature: −40 °C / +80 °C
•
Nominal current: 80 A
•
Nominal tension: 150 V
•
DC Power supply: +12 ... +24 V
•
Power consumption: 80 mA at 12 V DC
•
Electromagnetic environment CISPR 32: 2015
Class B
