LEM DCBM 100 Series User Manual

9/16
DCBM 100 Series
N° 99.W1.99.000.0
01March23/Version 1
DC ENERGY METER
6
Integration in the charging station/ Einbau in die Ladestation /
Intégration dans la station de charge
Current flow:
Direct: I1 I2
Reverse: I2 I1
Stromfluss:
Vorwärts: I1 I2
Rückwärts: I2 I1
Sens du courant :
Direct : I1 I2
Indirect : I2 I1
A
Meter
Meter
Compteur
C
Current flow
Stromfluss
Sens du courant
B
Ethernet Cable
Ethernet Kabel
Câble Ethernet
D
Charging station cable
Ladestation Kabel
Câble de la station de charge
Direct current flow
Product integration
E
B
C
A
I2I1
D
Reverse current flow
B
A
I1I2
C
D
I4
I3
I1
I2
12-24V
-
+
–+
I4
I3
I1
I2
12-24V
-
+
–
+
Direct current flow
Reverse current flow
