Spare Part ListSpare Part List
Spare Part ListSpare Part List
Spare Part List
Legend
EU = Europe Version
US = US Version
code description
PROCON 400/750PROCON 400/750
PROCON 400/750PROCON 400/750
PROCON 400/750
Assembly
130285 Mains Cable (EU)
110291 16A 250Vac Bipolar Power Switch
020493 100n 250Vac MKP EMI Capacitor “Siemens”
HGB238001 Transformer 230Vac 550W (EU) (Procon 400)
HGB238002 Transformer 230Vac 900W (EU) (Procon 750)
080608 36MB20A 35A 200V Rectifier Diode Bridge
HGB030000 10000u 80V -10+50% V Electrolytic Capacitor VT
110038 T16A Fuse 6.3x32mm (EU)(US) (Procon 750)
110027 T10A Fuse 6.3x32mm (EU)(US) (Procon 400)
141200 Speakon Socket (NL4MP Neutrik)
HGB347000 Volume Knob
HGB140000 Dual Red/Blk Binding Post
HGB110300 12Vdc 0.25A 80x25mm Fan
110360 Fan Grid 80mm
Input, Protection & Supply BoardInput, Protection & Supply Board
Input, Protection & Supply BoardInput, Protection & Supply Board
Input, Protection & Supply Board
HGB768012 * I
nput, Protection & Supply Board (PCBA HQ7.7332)(Procon750)
HGB768011 *
Input, Protection & Supply Board (PCBA HQ7.7302)(Procon400)
HGB140001 * 2sw 2pos H Slider Switch
HGB140002 * Hor Female XLR Socket
HGB140003 * Jack Horizontal S-F Socket
HGB110301 * Relay 12V / 2 Switch 10A 250Vac
HGB100000 * TA7317P Speaker Protection Circuit
HGB090009 * 2SA965-O TO92 Pnp Transistor
HGB090007 * 2SC2235-O TO92 Npn Transistor
HGB090000 * 2SC2240GR TO92 LN Npn Transistor
110011 * T1A Fuse 5x20mm (EU)
100061 * TL072 Dual J-Fet Operational Amplifier
100045 * 7812 +12V 1A Voltage Regulator
090200 * 2N5550/1 TO92 Npn Transistor
080158 * 1N4004 1A 400V Rectifier Diode
080103 * 1N4148 100mA 75V Signal Diode
060521 * 2K2 2W 10% Resistor
060253 * 10E 5W 10% Wire Resistor
050691 * 470K 1/4W 5% Resistor
050651 * 220K 1/4W 5% Resistor
050571 * 47K 1/4W 5% Resistor
050561 * 39K 1/4W 5% Resistor
050541 * 27K 1/4W 5% Resistor
050531 * 22K 1/4W 5% Resistor
050511 * 15K 1/4W 5% Resistor
050491 * 10K 1/4W 5% Resistor
050471 * 6K8 1/4W 5% Resistor
050401 * 1K8 1/4W 5% Resistor
050391 * 1K5 1/4W 5% Resistor
050381 * 1K2 1/4W 5% Resistor
050371 * 1K 1/4W 5% Resistor
050301 * 270E 1/4W 5% Resistor
050291 * 220E 1/4W 5% Resistor
050231 * 68E 1/4W 5% Resistor
030721 * 1000u 25V 20% Vert Electrolytic Capacitor
030650 * 470u 25V 20% Vert Electrolytic Capacitor
030565 * 220u 25V 20% Vert Electrolytic Capacitor
030485 * 100u 25V 20% Vert Electrolytic Capacitor
030403 * 47u 25V 20% Vert Electrolytic Capacitor
030324 * 22u 50V 20% Vert Electrolytic Capacitor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
021024 * 100n 63V 10% MKT Polyester Capacitor
010595 * 100n 50V -20+80% Ceramic Cap. Multilayer
010443 * 680p 50V 10% CL2 Ceramic Capacitor
010335 * 100p 500V 10% CL2 Ceramic Capacitor
010200 * 6p8 50V 10% CL2 Ceramic Capacitor
Volume BoardVolume Board
Volume BoardVolume Board
Volume Board
HGB768001 Volume Board (PCBA HQ7.7.179)
HGB075000 * 50KA RK16 Hor Rotary Potentiometer K15 40CLK
Display BoardDisplay Board
Display BoardDisplay Board
Display Board
HGB768002 Display Board (PCBA HQ7.7301)
MDL090000 * 9014C Npn TO92 Ebc 50V 0,15A
080158 * 1N4004 1A 400V Rectifier Diode
070181 * 10K 20% Horizontal Linear Trimmer
050571 * 47K 1/4W 5% Resistor
050491 * 10K 1/4W 5% Resistor
050381 * 1K2 1/4W 5% Resistor
050371 * 1K 1/4W 5% Resistor
042634 * 20K0 1/4W 1% Metalized Film Resistor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
Amplifier ModuleAmplifier Module
Amplifier ModuleAmplifier Module
Amplifier Module
HGB768014 375+375W Amplifier Module (PCBA HQ7.7308)
HGB768013 200+200W Amplifier Module (PCBA HQ7.7307)
090201 * 2N5400/1 TO92 Pnp Transistor
090200 * 2N5550/1 TO92 Npn Transistor
HGB090008 * 2SC2690 TO126 Npn Transistor
HGB090010 * 2SA1220 TO126 Pnp Transistor
HGB090014 * 2SA1943 TO264 Pnp Transistor
HGB090013 * 2SC5200 TO264 Npn Transistor
HGB090006 * 2SA1941 TO3P/TO218 Pnp Transistor
HGB090005 * 2SC5198 TO3P/TO218 Npn Transistor
HGB090004 * 2SA970GR TO92 LN Pnp Transistor
HGB090001 * 2SC2001K TO92 Npn Transistor
HGB090000 * 2SC2240GR TO92 LN Npn Transistor
HGB080800 * Ntc type DKF503 (Thermometrics)
080158 * 1N4004 1A 400V Rectifier Diode
080103 * 1N4148 100mA 75V Signal Diode
060253 * 10E 5W 10% Wire Resistor
060210 * 4E7 2W 10% Resistor
050611 * 100K 1/4W 5% Resistor
050491 * 10K 1/4W 5% Resistor
050461 * 5K6 1/4W 5% Resistor
050301 * 270E 1/4W 5% Resistor
050131 * 10E 1/4W 5% Resistor
050091 * 4E7 1/4W 5% Resistor
030324 * 22u 50V 20% Vert Electrolytic Capacitor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
020481 * 100n 100V10% MKT Polyester Capacitor
010595 * 100n 50V -20+80% Ceramic Cap. Multilayer
010335 * 100p 500V 10% CL2 Ceramic Capacitor
PROCON 950/1100/1250/1500PROCON 950/1100/1250/1500
PROCON 950/1100/1250/1500PROCON 950/1100/1250/1500
PROCON 950/1100/1250/1500
Assembly
130285 Mains Cable (EU)
110291 16A 250Vac Bipolar Power Switch
020493 100n 250Vac MKP EMI Capacitor “Siemens”
HGB238003 Transformer 230Vac 1100W (EU) (Procon 950)
HGB238004 Transformer 230Vac 1200W (EU) (Procon 1100)
HGB238005 Transformer 230Vac 1600W (EU) (Procon 1250)
HGB238006 Transformer 230Vac 1900W (EU) (Procon 1500)
080608 36MB20A 35A 200V Rectifier Diode Bridge
HGB030002 10000u 110V -10+50% V Electrolytic Capacitor VT (Procon1250/1500)
HGB030001 10000u 100V -10+50% V Electrolytic Capacitor VT (Procon950/1100)
110063 T25A Fuse 6.3x32mm (EU)(US) (Procon 1500)
110062 T20A Fuse 6.3x32mm (EU)(US) (Procon 1250)
110038 T16A Fuse 6.3x32mm (EU)(US) (Procon 950/1100)
141200 Speakon Socket (NL4MP Neutrik)
HGB347000 Volume Knob
HGB140000 Dual Red/Blk Binding Post
HGB110300 12Vdc 0.25A 80x25mm Fan (Procon 950/1100)
HGB110302 12Vdc 0.45A 80x25mm Fan (Procon 1250/1500)
110360 Fan Grid 80mm
Soft Start BoardSoft Start Board
Soft Start BoardSoft Start Board
Soft Start Board
768272 Soft Start Board (Pcb#313114) (NL version only)
140917 * 2 Contacts Vert Male Connector
120857 * 6.3mm Vertical Male Faston for Pcb
110324 * Relay NO 1 SC.12V 20A R=160E
090152 * BC337 TO92 Npn Transistor
080156 * 1N4002 1A 100V Rectifier Diode
080103 * 1N4148 100mA 75V Signal Diode
061341 * 68E 20W 5% Wire Resistor
052060 * 100K 1/8w 5% Resistor
052056 * 47K 1/8w 5% Resistor
052048 * 10K 1/8w 5% Resistor
030403 * 47u 25V 20% Vert Electrolytic Capacitor
020493 * 100n 250Vac MKP EMI Capacitor “Siemens”
010595 * 100n 50V -20+80% Ceramic Cap. Multilayer
Input, Protection & Supply BoardInput, Protection & Supply Board
Input, Protection & Supply BoardInput, Protection & Supply Board
Input, Protection & Supply Board
HGB768000 Input, Protection & Supply Board (PCBA HQ7.7333)
(Procon950/1100/1250/1500)
HGB140001 * 2sw 2pos H Slider Switch
HGB140002 * Hor Female XLR Socket
HGB140003 * Jack Horizontal S-F Socket
HGB110301 * Relay 12V / 2 Switch 10A 250Vac
HGB100000 * TA7317P Speaker Protection Circuit
HGB090008 * 2SC2690 TO126 Npn Transistor
110012 * T1.6A Fuse 5x20mm (EU) (Procon1100/1250/1500)
110011 * T1A Fuse 5x20mm (EU) (Procon950)
100061 * TL072 Dual J-Fet Operational Amplifier
100045 * 7812 +12V 1A Voltage Regulator
100043 * 7912 -12V 1A Voltage Regulator
090201 * 2N5400/1 TO92 Pnp Transistor
090200 * 2N5550/1 TO92 Npn Transistor
080158 * 1N4004 1A 400V Rectifier Diode
060253 * 10E 5W 10% Wire Resistor
050691 * 470K 1/4W 5% Resistor
050671 * 330K 1/4W 5% Resistor
050641 * 180K 1/4W 5% Resistor
050621 * 120K 1/4W 5% Resistor
050581 * 56K 1/4W 5% Resistor
050571 * 47K 1/4W 5% Resistor
050551 * 33K 1/4W 5% Resistor
050521 * 18K 1/4W 5% Resistor
050491 * 10K 1/4W 5% Resistor
050481 * 8K2 1/4W 5% Resistor
050451 * 4K7 1/4W 5% Resistor
050441 * 3K9 1/4W 5% Resistor
050431 * 3K3 1/4W 5% Resistor
050251 * 100E 1/4W 5% Resistor
050131 * 10E 1/4W 5% Resistor
042634 * 20K0 1/4W 1% Metalized Film Resistor
030721 * 1000u 25V 20% Vert Electrolytic Capacitor
030650 * 470u 25V 20% Vert Electrolytic Capacitor
030565 * 220u 25V 20% Vert Electrolytic Capacitor
030485 * 100u 25V 20% Vert Electrolytic Capacitor
030403 * 47u 25V 20% Vert Electrolytic Capacitor
030324 * 22u 50V 20% Vert Electrolytic Capacitor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
030005 * 1u 50V 20% Vert Electrolytic Capacitor
021024 * 100n 63V 10% MKT Polyester Capacitor
021012 * 10n 63V 10% MKT Polyester Capacitor
010595 * 100n 50V -20+80% Ceramic Cap. Multilayer
010200 * 6p8 50V 10% CL2 Ceramic Capacitor
Volume BoardVolume Board
Volume BoardVolume Board
Volume Board
HGB768001 Volume Board (PCBA HQ7.7.179)
HGB075000 * 50KA RK16 Hor Rotary Potentiometer K15 40CLK
Display BoardDisplay Board
Display BoardDisplay Board
Display Board
HGB768002 Display Board (PCBA HQ7.7301)
MDL090000 * 9014C Npn TO92 Ebc 50V 0,15A
080158 * 1N4004 1A 400V Rectifier Diode
070181 * 10K 20% Horizontal Linear Trimmer
050571 * 47K 1/4W 5% Resistor
050491 * 10K 1/4W 5% Resistor
050381 * 1K2 1/4W 5% Resistor
050371 * 1K 1/4W 5% Resistor
050481 * 8K2 1/4W 5% Resistor
042634 * 20K0 1/4W 1% Metalized Film Resistor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
Power Amplifier ModulePower Amplifier Module
Power Amplifier ModulePower Amplifier Module
Power Amplifier Module
HGB768010 CH1-750W Amplifier Module (PCBA HQ7.7312)
HGB768009 CH2-750W Amplifier Module (PCBA HQ7.7311)
HGB768008 CH1-625W Amplifier Module (PCBA HQ7.7198)
HGB768007 CH2-625W Amplifier Module (PCBA HQ7.7198)
HGB768006 CH1-550W Amplifier Module (PCBA HQ7.7198)
HGB768005 CH2-550W Amplifier Module (PCBA HQ7.7198)
HGB768004 CH1-475W Amplifier Module (PCBA HQ7.7314)
HGB768003 CH2-475W Amplifier Module (PCBA HQ7.7314)
HGB090014 * 2SA1943 TO264 Pnp Transistor
HGB090013 * 2SC5200 TO264 Npn Transistor
HGB090006 * 2SA1941 TO3P/TO218 Pnp Transistor
HGB090005 * 2SC5198 TO3P/TO218 Npn Transistor
HGB090004 * 2SA970GR TO92 LN Pnp Transistor
HGB090003 * 2SA940A TO220F Pnp Transistor
HGB090002 * 2SC2073A TO220F Npn Transistor
HGB090001 * 2SC2001K TO92 Npn Transistor
HGB090000 * 2SC2240GR TO92 LN Npn Transistor
HGB080800 * Ntc type DKF503 (Thermometrics)
HGB080000 * FR107 OR BA159 Fast Rec Diode 1A 1000V 500ns DO41
HGB061000 * 10K 4W 10% Resistor
230557 * 1uH Horizontal Coil For Amplifier
120857 * 6.3mm Vertical Male Faston for Pcb
080103 * 1N4148 100mA 75V Signal Diode
070201 * 22K 20% Horizontal Linear Trimmer
070106 * 470E 20% Horizontal Linear Trimmer
060336 * 47E 2W 10% Resistor
060253 * 10E 5W 10% Wire Resistor
060210 * 4E7 2W 10% Resistor
060151 * 1E 5W 10% Wire Resistor
052047 * 8K2 1/8w 5% Resistor
050571 * 47K 1/4W 5% Resistor
050541 * 27K 1/4W 5% Resistor
050531 * 22K 1/4W 5% Resistor
050511 * 15K 1/4W 5% Resistor
050491 * 10K 1/4W 5% Resistor
050421 * 2K7 1/4W 5% Resistor
050371 * 1K 1/4W 5% Resistor
050351 * 680E 1/4W 5% Resistor
050301 * 270E 1/4W 5% Resistor
050291 * 220E 1/4W 5% Resistor
050271 * 150E 1/4W 5% Resistor
042634 * 20K0 1/4W 1% Metalized Film Resistor
040134 * 10E 1/2W 5% Resistor
040091 * 4E7 1/2W 5% Resistor
030410 * 47u 50V 20% Vert Electrolytic Capacitor
030403 * 47u 25V 20% Vert Electrolytic Capacitor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
020481 * 100n 100V10% MKT Polyester Capacitor
010426 * 470p 50V 10% CL2 Ceramic Capacitor
010345 * 100p 50V 10% CL2 Ceramic Capacitor
010335 * 100p 500V 10% CL2 Ceramic Capacitor
010293 * 33p 50V 10% CL2 Ceramic Capacitor
010282 * 27p 50V 10% CL2 Ceramic Capacitor
Note:Note:
Note:Note:
Note:
- All dimensions are in mm unless otherwise specified.
- Each spare part is single quantity unless otherwise specified.
- Asterisk prefix explanation:
Omitted = First level spare part.
One asterisk = Second level, part of previous listed first level part.
Two asterisk = Third level, part of previous listed second level part.
Three asterisk = ............
- Any request for not above mentioned part must encompass specific description
including:
1) Model name,
2) Section name,
3) Module code,
4) Reference name,
5) Quantity number.
To Previous Page
Loading...
