rx 200
9
3. +48V
+48V Phantom power supply buttons: activates +48V
power supply on the MIC inputs of the MONO input
channels.
NOTE
When the PHANTOM power supply is needed, make
certain that cables with BALANCED XLR connectors are
ALWAYS used to connect the microphones: this
precaution is extremely important for avoiding damage
in the event of both condenser and normal (dynamic)
microphones being used simultaneously. Switch on the
PHANTOM power supply only after having connected
the condenser microphone to the input and only with
the channel fader closed to avoid output signal peaks.
No. Name Pre-delay Rev Time Room Size Hi Damp Rev Type
1 WARM HALL 45 3.60 41 -12,00
2 BRIGHT HALL 23 2.90 28 -0,96
3 WARM ROOM 45 2.10 17 -12,00
4 BRIGHT ROOM 23 2.10 9 -0,96
5 VOCAL 1 0 4,50 10 -0,96 Spring
6 VOCAL 2 25 2,40 9 -0,96 Spring
7 VOCAL 3 114 1,00 10 -0,96 Hall
8 PLATE 10 2.90 10 -2,08
No. Name Left Delay Right Delay Left F.B. Right F.B.
9 STEREO DELAY 1 352 176 40 72
10 STEREO DELAY 2 238 119 36 73
No. Name Rev Time Room Size Left Delay Right Delay Left F.B. Right F.B. Rev level
11 REV + DELAY 1 2,90 39 326 163 28 67 80%
12 REV + DELAY 2 2,40 39 211 107 28 49 80%
13 REV + DELAY 3 2,10 26 375 187 48 82 90%
14 REV + DELAY 4 1,50 26 277 138 28 67 90%
No. Name Rev Time Room Size Mod. Freq. Pitch. Depth Mod level Rev level
15 REV + CHORUS 1 2,90 39 3,67 40 100 90%
16 REV + CHORUS 2 1,50 26 3,02 40 100 90%
RX 200 - PRESET LIST
4. POWER
Mixer on/off switch.
5. Power supply socket / Main fuse holder
In the event of breaking, always replace the fuse with
same type and rating.
