LENCO SB-0160 - Soundbar System Assembly Guide

7
V鋘sterh鰃talare
D. Assembly
Follow the below pictures to assemble the Soundbar system.
Be sure all the connections are firmly joint.
Picture 1, simple connection
Left speaker
Connector
Right speaker
1. Follow Picture 1 to assemble the left and right Speakers with 1
Connector.
A basic connection:
Use one connector to connect with speakers. Press the buttons
when insert or pull open the L/R Speakers from connector.
Picture 2, full connection
Extension tube
Left speaker
Connector
Screws
Screws
Right speaker
Connector
2. Follow Picture 2 to assemble the Speakers with 2 Connectors and
Extension tube.
A full connection:
Use the 200mm Extension tube or 250mm Extension tube to connect
with the speakers and connectors.
Press the buttons when insert or pull open the L/R Speakers and
connectors. Press the buttons when insert or pull open the L/R
Speakers from the connectors and fix the nails into the holes to firmly
connect the parts. (You can only use one Extension tube at a time)
