Single Reader Interface Module LNL-1300 Series 3 Quick Reference
© 2020 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 4 QR50L-1033E — revision 3.004
Communication Baud Rate
Bus Encryption
Status LEDs
Power-up: All LEDs OFF.
Initialization: Once power is applied, initialization of the module begins.
The D1 LED is turned ON at the beginning of initialization.
Run time: After the above sequence, the LEDs have the following
meanings:
D1 LED: Heartbeat and On-Line Status:
• Off-line: 1 second rate, 20% ON, 80% OFF
• On-line:
- Non-encrypted communication: 1 second rate, 80% ON, 20%
OFF
- Encrypted communication: 0.1 sec ON, 0.1 sec OFF, 0.1 sec
ON, 0.1 sec OFF, 0.1 sec ON, 0.1 sec OFF, 0.1 sec ON, 0.3 sec
OFF
D1 LED: Error Indication:
Waiting for application firmware to be downloaded: 0.1 sec ON, 0.1 sec
OFF
D2 LED: Serial I/O Communication Port Status:
Indicates communication activity on the serial I/O communication port
Specifications
The LNL-1300 is for use in low voltage, class 2 circuit, only. These
specifications are subject to change without notice.
• Primary power: 12 to 24 VDC ± 10%, 150 mA maximum (plus reader
current)
• Outputs: Two (2) Form-C relays:
- K1: Normally Open (NO) contact: 5 A @ 30 VDC resistive
Normally Closed (NC) contact: 3 A @ 30 VDC resistive
- K2: 1 A @ 30 VDC resistive
• Inputs:
- Two (2) unsupervised/supervised, standard EOL, 1k/1k ohm,
1%, ¼ watt
- One (1) unsupervised, dedicated for cabinet tamper
• Reader interface:
- Reader power: 12 to 24 VDC ± 10% (input voltage passed
through)
- Reader LED output: TTL compatible, high > 3 V, low < 0.5 V,
5 mA source/sink maximum
- Buzzer output: Open collector, 12 VDC open circuit maximum,
40 mA sink maximum
- Data inputs: TTL compatible, F/2F or 2-wire RS-485
• Communication: 2-wire RS-485: 9600, 19200, 38400, or 115200 bps
• Cable requirements:
- Power: 1 twisted pair, 18 AWG
- RS-485 I/O devices: 1 twisted pair with drain wire and shield,
24 AWG, 120 ohm impedance, 4000 feet (1219 m) maximum
- Alarm inputs: 1 twisted pair per input, 30 ohms maximum
- Output: As required for the load
- Reader data (TTL): 6-conductor, 18 AWG, 500 feet (150 m)
maximum
- Reader data (F/2F): 4-conductor, 18 AWG, 500 feet (150 m)
maximum
- Reader data (RS-485): 24 AWG, 120 ohm impedance, twisted
pair with drain wire and shield, 2000 feet (610 m) maximum
Mechanical:
- Dimension: 4.25 x 2.75 x 1 in. (108 x 70 x 25.4 mm)
- Weight: 4 oz. (120 g) nominal
• Environmental:
- Temperature: -55 to +85°C storage, -40 to +75°C operating
- Humidity: 5% to 95% RHNC
UL 294, 7th edition Performance Levels:
Note: Outputs are Power limited/class 2 when powered by external
power limited/class 2 power supply model LNL-AL400ULX or
LNL-AL600ULX-4CB6.
Baud rate DIP switch 6: DIP switch 7:
38,400 bps ON ON
19,200 bps off ON
9600 bps ON off
115,200 bps off off
Bus communications DIP switch 8:
(OnGuard 2009
or later)
DIP switch 8:
(prior to
OnGuard 2009)
Encryption is not required off Normal operation
Encryption is required ON Not allowed
Feature Level
Standby Power I
Endurance IV
Line Security I
Destructive Attack I
