13ACX SERIES
Start-Up and Performance Checklist
Job Name Job no. Date
Job Location City State
Installer City State
Unit Model No. Serial No. Service Technician
Nameplate Voltage
Rated Load Ampacity Compressor Outdoor Fan
Maximum Fuse or Circuit Breaker
Electrical Connections Tight?  Indoor Filter clean?  Supply Voltage (Unit Off)
Indoor Blower RPM S.P. Drop Over Indoor (Dry) Outdoor Coil Entering Air Temp.
Discharge Pressure Suction Pressure Refrigerant Charge Checked? 
Refrigerant Lines: Leak Checked?  Properly Insulated?  Outdoor Fan Checked? 
Service Valves: Fully Opened?  Caps Tight?  Thermostat
Voltage With Compressor Operating Calibrated?  Properly Set?  Level? 

Lennox 14ACX Specifications

General

Compressor Type	Single-stage
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Refrigerant	R-410A
Energy Star Certified	No
Voltage	208/230V
Phase	1
Unit Weight	Varies by model
Dimensions (H x W x D)	Varies by model
SEER Rating	14
Cooling Capacity	1.5 to 5 tons
Sound Level (dBA)	76
