14ACX SERIES
Component Specifications
Table 1. Field Replaceable Components
Model Numbers Contactor (K1) Run Capacitor (C12) Liquid Line Drier Crankcase Heater (HR1)
14ACX-018-230-XX (All) 1-Pole, 25A 30 + 5 MFD @ 440V Round
R410A - One Way - 55G
N/A
14ACX-024-230-XX (All)
1-Pole, 25A
35 + 5 MFD @ 440V Round
14ACX-030-230-XX (All) 40 + 5 MFD @ 440V Round
14ACX-036-230-XX (All) 45 + 5 MFD @ 440V Round
14ACX-041-230-01
1-Pole, 35A
45 + 10 MFD @ 440V Round
40W 240V 04.72-7.01
14ACX-042-230-XX (All) N/A
14ACX-047-230-01 70W 240V 06.35-8.64
14ACX-048-230-01 through
-10
70 + 10 MFD @ 440V Oval 70W 240V 06.35-8.64
14ACX-048-230-11, -12,
-13, -14, -15, -16
1-Pole, 35A 70 + 10 MFD @ 440V Round 70W 240V 06.35-8.64
14ACX-059-230-XX (All)
1-Pole, 35A
70 + 10 MFD @ 440V Round 70W 240V 06.35-8.64
14ACX-060-230-01 through
-10
70 + 10 MFD @ 440V Oval 70W 240V 06.35-8.64
14ACX-060-230-11, -12 1-Pole, 35A 70 + 10 MFD @ 440V Round 70W 240V 06.35-8.64
14ACX-060-230-13, -14 1-Pole, 35A 75 + 10 MFD @ 440V Round 70W 240V 06.35-8.64
Table 2. Service Valves Sizes and Refrigerant Line Set Recommendations
Model Number
Valve Field Size Connections Recommended Line Set
Liquid Line Suction Line Liquid Line Suction Line L15 Series Line Sets
14ACX-018-230-XX (All)
3/8 in. (10 mm) 3/4 in. (19 mm) 3/8 in. (10 mm) 3/4 in. (19 mm)
L15-41 — 15 feet to 50 feet (4.6
meters to 15 meters)
14ACX-024-230-XX (All)
14ACX-030-230-XX (All)
14ACX-036-230-XX (All)
3/8 in. (10 mm) 7/8 in. (22 mm) 3/8 in. (10 mm) 7/8 in. (22 mm)
L15-65 — 15 feet to 50 feet (4.6
meters to 15 meters)
14ACX-041-230-01
14ACX-042-230-XX (All)
14ACX-047-230-01
14ACX-048-230-XX (All)
14ACX-059-230-XX (All)
3/8 in. (10 mm) 1-1/8 in. (29 mm) 3/8 in. (10 mm) 1-1/8 in. (29 mm) Field Fabricated
14ACX-060-230-XX (All)
NOTE — Some applications may required a field provided 7/8” to 1-1/8” adapter
