BALTIC R410A-IOM-0708-E Page 74
Connection HWC B box Connection HWC C box
Connection HWC D box Connection HWC E box
Pipe Internal Diameters (DN)
MAXIMUM WORKING PRESSURE: 8 BARS
MAXIMUM WORKING TEMPERATURE: 110°C
B020 B030 B035 B045 B055 B065 B075
H 20 20 20 25 25 25 25
Fig. 46
