IOM / ROOFTOP BALTIC Series - 0704-E Page 101
control interfaces ds50 menu tree
ALL CODES SHOWING (1) CAN BE ADJUSTED FOR EACH TIME ZONE
Main Screen Code Description Code Description Code Description Code UNIT Min Factory Max Description
3-Hot W/Coil 2630 Config. 2631 List [No / Modulation]
State 2632 List [Stopped / Air Flow / Start / Schedule
/ Switch / Fault (1) / Fault (2)]
Opening 2633 %
Sw Freeze 2634 On/Off
Sw Disable 2635 On/Off
4-Pump 2640 Config. 2641 List [No / Yes]
State 2642 List [Stopped / Air Flow / Fault (1) / Start]
Sw State 2643 On/Off
Relay 2644 On/Off
7-Humidif. 2700 2710 Config. 2711 List [No / Modulation]
State 2712 List [Stopped / Air Flow / Schedule / Fault (1) / Start]
Sw State 2713 On/Off
Modulat. 2714 %
8-Com. 2800 1-Outside 2810 Value 2811 °c
Sensor 2812 °c
Link 2813 °c
BMS 2814 °c
Value 2815 %.
Sensor 2816 %.
Link 2817 %.
BMS 2818 %.
2-Room 2820 Value 2821 °c
Sensor 2822 °c
Link 2823 °c
BMS 2824 °c
Value 2825 %.
Sensor 2826 %.
Link 2827 %.
BMS 2828 %.
To Next Page
