control interfaces ds50 menu tree
Main Screen Code Description Code Description Code Description Code UNIT Min Factory Max Description
3-Control 3300 1-Customer 3310 Sp Room 3311 °c 8 20 35 [Room SP] Required room temperature set point
in °C. Middle of the dead zone.
Mini.Air 3312 % 0 20 100 [Room SP] Required room minimum fresh air
rate in % Middle of the dead zone.
2-Room 3320 Sp Dyna 3321 °c 0 99.9 99.9 [Room SP] Required value for the Dynamic Set
Point. Allows the room set point to change according to outdoor temperature
Sp Cool 3322 °c 8 21 35 [Room SP] Required maximum room
emperature in °C. Cooling set point
Sp Heat 3323 °c 8 19 35 [Room SP] Required minimum room temperature
in °C. Heating set point
Swap Heater 3324 Yes/No ~ No ~ [OFF] Heat Pump and then Heater [ON] Heater
and then Heat Pump
3-Reheat 3330 Activation 3331 Yes/No ~ No ~ [F-Air Reheat] Activate reheating of the fresh air in
the dead zone to maintain supply temperature.
Swap Heater 3332 Yes/No ~ No ~ [F-Air Reheat] Prioritise the heating mode for
fresh air reheat. [OFF] Heat Pump and then Heater [ON] Heater and then Heat Pump
4-Humidity 3340 Sp Dehu 3341 % 0 100 100 [Humidity] Desired Maximum relative humidity in
Room (in %). - Dehumidification set point.
Sp Humi 3342 % 0 0 100 [Humidity] Desired Minimum relative humidity in
Room (in %). - Humidification set point.
5-Enable 3350 Fan On/Off 3351 Yes/No ~ Yes ~ [Enable] Stopping and running of the Fan
Blower.[OFF] the blower is stopped, [ON] the blower is running.
Fan Dead 3352 Yes/No ~ Yes ~ [Enable] Stopping and running of the fan in the
"Control Dead Zone". [OFF] the blower is stopped, [ON] the blower is running.
F.Air 3353 Yes/No ~ Yes ~ [Enable] Run eco: [ON] the Economiser is
running, [OFF] the Economiser if stopped.
CO2 3354 Yes/No ~ Yes ~ [Enable] Run CO2 Sensor: [ON] Switch-on the
CO2 on a Zone, [OFF]Stop the CO2 sensor on a zone.
Comp.Cool. 3355 Yes/No ~ Yes ~ [Enable] [OFF] Force the unloading of
compressors in cooling mode.
Comp.Heat. 3356 Yes/No ~ Yes ~ [Enable] [OFF] Force the unloading of
compressors in heating mode.
AuxHeat 3357 Yes/No ~ Yes ~ [Enable] [OFF] Force the unloading of heating
module (electric, gas or heat water coil)
Humidif. 3358 Yes/No ~ Yes ~ [Enable] [OFF] Force the unloading of humidity
control.
Low Noise 3359 Yes/No ~ No ~ [Enable] Force the noise reduction mode.
[ON] 50% of the compressors are unloaded in
"Unoccupied" zone
