control interfaces ds50 menu tree
Main Screen Code Description Code Description Code Description Code UNIT Min Factory Max Description
5-Fresh Air 3500 .. 3510 Out.Limit 3511 °c -20 -20 40 [Fresh air Damper] minimum outdoor
temperature limit in °C. If the outdoor temperature is lower than this limit the control in free cooling is not allowed. The fresh air damper is then set to the minimum setting.
.. Maximum 3512 % 0 100 100 [Fresh air Damper] Maximum allowable opening
of the fresh air damper in %
.. Start Ext 3513 % 0 30 100 [Extraction] Threshold of activation of the power
exhaust fan according to the position of the economiser damper in %.
.. Mini.Co2 3514 ppm 0 1000 2000 [CO2] Fresh air damper minimum opening
threshold in ppm
.. Maxi.Co2 3515 ppm 0 1500 2000 [CO2] Fresh air damper maximum opening limit
in ppm
.. Calib. 3516 Yes/No ~ Yes ~ Allow the calibration of the minimum fresh air. .. Recovery 3517 Yes/No ~ No ~ [NO/YES] Heat recovery
6-Compressor 3600 1-Out.Limit 3610 Cool. 50 3611 °c
-10 or 10 20 40
[ Limit of Regulation ] * 1° If Option Regulation all seasons - Reduction speed of the fans condenser - Threshold of outside temperature (in °c). - If the outside temperature is lower than this threshold the fans condenser function in low speed * 2° If not - Unloading 50% of the Compressors in Cooling - Threshold of outside temperature (in °c). - If the outside temperature is lower than this threshold 50% of the compressors are used by the Regulation
Cool.100 3612 °c
-10 or 10 12 40
[ Limit of Regulation ] * 1° If Option Regulation all seasons - Stopping of the fans condenser - threshold of outside temperature (in °c). - If the outside temperature is lower than this threshold the fans condenser are stopped * 2° If not - Unloading 100% of the Compressors in Cold - Threshold of outside temperature (in °c). - If the outside temperature is lower than this threshold the compressors are not used by the Regulation
Heat.100 3613 °c -50 -20 40 [ Limit of Regulation ] Unloading 100% of the
Compressors in Heating - Threshold of outside temperature (in °c). - If the outside temperature is lower than this threshold the compressors are not used by the Regulation.
