Page 106 - IOM / ROOFTOP BALTIC Series - 0704 - E
Main Screen Code Description Code Description Code Description Code UNIT Min Factory Max Description
2-Defrost 3620 Type 3621 List 0 0 1 [ Function Defrost ] Choice of defrost:
1 = "cycling" or 0 = dynamic
Outside 3622 °c 8 10 20 [ Function Defrost ] Authorization of defrost -
Threshold of outside temperature (in °c)
Coil 3623 °c -10 -2 10 [ Function Defrost ] Authorization of defrost -
Threshold of coil temperature (in °c)
Time Limit 3624 m 30 45 90 [ Function Defrost ] Time limit for icing (in minute)
-For the dynamic defrost the unit will run this
minimum amount of time. If cycling defrost this is
the time delay to start the defrost once the
temperature conditions are met.
Time Fc 3625 ~ 1 3 5 [ Function Defrost ] Number of condenser fan
start-ups to end defrost. If the number of start-ups
can not be achieved within 4min the defrost
will end.
3-Safety 3630 W/Cd Mini 3631 °c 4 5 20 [Safety limit] Low Temperature Limit for water heat
exchanger output (in °c) - Threshold of activation
of the safety limit.
W/Cd Maxi 3632 °c 20 45 46 [safety limit] High Temperature Limit for water
heat exchanger output (in °c) - Threshold of
activation of the safety limit.
7-Heater 3700 1-Gas 3710 . 3711
2-Elec. H. 3720 Out.Limit 3721 °c -20 10 40 [ Limit of Regulation ] Unloading 100% of heaters
- Threshold of outside temperature (in °c). If the
outside temperature is higher than this threshold
Heaters are switched off.
Sp Mixing 3722 °c 0 5 10 [ Electrical heater ] Regulation all seasons of
FLEXY FX - Threshold of temperature of mixture
(in °c) - If the temperature of mixture is lower than
this threshold Electrical Heaters are activated
Maximum 3723 % 0 100 100 [ Electrical heater ] For Electric Heater with Triac:
Maximum power of use of Electrical heater (in %)
3-Hot W/Coil 3730 Out.Limit 3731 °c -20 10 40 Authorise a leak-flow
Opening 3732 % 0 0 50
A.Freeze 3733 List 0 0 ? [0% / 100%] Open or close the V3V
4-Pump 3740 Mode 3741 List 0 0 ? [No/Frost.Al./Start heat/Start] Choose startup
mode for the pump
control interfaces ds50 menu tree
