IOM / ROOFTOP BALTIC Series - 0704-E Page 107
Main Screen Code Description Code Description Code Description Code UNIT Min Factory Max Description
8-Config. 3800 1-Unit 3810 Range 3811 List 0 6 ? Type of unit: BC, BH, BGN, BG, BD, FC, FH, FGN,
FG, FD, FX or FW
Size 3812 List 0 0 ? See table n° 5 Page 110
Hu. Pack 3813 Yes/No ~ No ~ [ Configuration ] Activation of the Humidity
Management Option
TCB 3814 Yes/No ~ No ~ [Configuration] Configuration of the Thermostat
Control Board.
2-Compressor 3820 LAK 3821 Yes/No ~ No ~ [ Configuration ] Low Ambient Kit "all season
control"
Wat/Cond 3822 Yes/No ~ No ~
085/100 + 3823 Yes/No ~ No ~ [ Configuration ] Activation of the "Optimized
Defrost" Option. Only for Flexy 85_100
with split airflow.
3-Option 3830 AuxHeat 3831 List 0 0 6 [ Configuration ] Configuration of the Heating
Input: HWC; Electric Heater S/M/H or
Gas 2/4/2 pro. /4 pro. For 20kW ' 60kW choose
"gas 2"; for 120kW ' 180kW choose "gas 4";
"pro." means modulating gas
F.Air 3832 List 0 0 3 [ Configuration ] Configuration of the Fresh Air /
Economiser: NO, 100% fixed or 0-50% or 0-100%
Modulating.
P. Air 3833 List 0 0 2 [ Configuration ] Configuration of the differential
pressure sensor: 0Pa; 500Pa; 1000Pa
control interfaces ds50 menu tree
