ELECTRIC HEAT DATA — CB19/CBH19-31,-41
Blower Coil Unit
Model Number
Electric Heat Model Number
& Shipping Weight
Number of
Steps & Phase
Volts
Input
kW
Input
**Btuh
Input
DBlower
Amps
*Minimum
Circuit Ampacity
Model
Number
&
Shipping
Weight
Steps
&
Phase
Input
Input
Input
Amps
Circuit 1 Circuit 2
208 3.8 12,800 3.0 25.0 - - - -
ECB19-5
(69G87)
1 step
h
220 4.2 14,300 3.0 26.3 - - - -
(69G87)
4 lbs. (2 kg)
1 phase
230 4.6 15,700 3.0 27.4 - - - -
240 5.0 17,100 3.0 28.4 - - - -
208 4.5 15,400 3.0 29.5 - - - -
ECB19-6
(69G88)
2 steps
220 5.0 17,100 3.0 30.8 - - - -
(69G88)
5 lbs. (2 kg)
p
1 phase
230 5.5 18,800 3.0 32.4 - - - -
240 6.0 20,500 3.0 33.7 - - - -
208 5.3 17,900 3.0 34.0 - - - -
ECB19-7
(69G89)
2 steps
220 5.9 20,100 3.0 35.9 - - - -
(69G89)
5 lbs. (2 kg)
p
1 phase
230 6.4 21,900 3.0 37.3 - - - -
240 7.0 23,900 3.0 38.9 - - - -
CB19-31
208 6.0 20,500 3.0 38.5 - - - -
CBH19-31
and
ECB19-8
(69G90)
2 steps
220 6.7 22,900 3.0 40.5 - - - -
and
CB19-41
CBH19 41
(69G90)
5 lbs. (2 kg)
p
1 phase
230 7.3 25,100 3.0 43.3 - - - -
CBH19-41
240 8.0 27,300 3.0 44.0 - - - -
208 7.5 25,600 3.0 47.4 - - - -
ECB19-10
(69G91)
2 steps
220 8.4 28,700 3.0 50.1 - - - -
(69G91)
5 lbs. (2 kg)
p
1 phase
230 9.2 31,400 3.0 52.3 - - - -
240 10.0 34,100 3.0 54.5 - - - -
208 9.4 32,000 3.0 40.0 18.9
ECB19-12.5
(68G92)
3 steps
220 10.5 35,800 3.0 42.2 19.9
(68G92)
10 lbs. (5 kg)
p
1 phase
230 11.5 39,200 3.0 44.0 20.8
240 12.5 42,600 3.0 45.8 21.8
208 11.3 38,400 3.0 47.5 22.7
ECB19-15
(69G93)
3 steps
220 12.6 43,000 3.0 50.1 23.9
(69G93)
10 lbs. (5 kg)
p
1 phase
230 13.5 47,000 3.0 52.3 25.0
240 15.0 51,200 3.0 54.5 26.0
208 3.8 12,800 3.0 15.4 - - - -
ECB19-5
(69G97)
3 steps
220 4.2 14,300 3.0 16.2 - - - -
(69G97)
6 lbs. (3 kg)
p
3 phase
230 4.6 15,700 3.0 16.8 - - - -
240 5.0 17,100 3.0 17.4 - - - -
208 5.6 19,200 3.0 21.9 - - - -
ECB19-7.5
(69G98)
3 steps
220 6.3 21,500 3.0 23.0 - - - -
(69G98)
6 lbs. (3 kg)
p
3 phase
230 6.9 23,500 3.0 24.0 - - - -
240 7.5 25,600 3.0 24.9 - - - -
208 7.5 25,600 3.0 28.4 - - - -
CB19-41
ECB19-10
(69G99)
3 steps
220 8.4 28,700 3.0 29.9 - - - -
CBH19-41
(69G99)
6 lbs. (3 kg)
p
3 phase
230 9.2 31,400 3.0 31.3 - - - -
240 10.0 34,100 3.0 32.5 - - - -
208 11.3 38,400 3.0 41.5 - - - -
ECB19-15
(70G00)
3 steps
220 12.6 43,000 3.0 43.7 - - - -
(70G00)
9 lbs. (4 kg)
p
3 phase
230 13.5 47,000 3.0 45.7 - - - -
240 15.0 51,200 3.0 47.5 - - - -
208 15.0 51,200 3.0 47.4 45.0
ECB19-20
(69G94)
3 steps
220 16.8 57,300 3.0 50.1 47.8
(69G94)
14 lbs. (6 kg)
p
1 phase
230 18.4 62,700 3.0 52.3 49.9
240 20.0 68,200 3.0 54.5 52.2
*Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements. Use wires suitable for at least 167°F (75_C).
**Electric heater capacity only — does not include additional blower motor heat capacity.
DMinimum circuit ampacity for blower motor only.
