Page 8
Table 7. CBX25UHV‐048 Air Handler Performance (0 through 0.80 in. w.g. External Static Pressure Range)
ADJUST
Jumper
Setting
BDC3 Jumper Speed Positions
HEAT Speed First-Stage COOL Speed Second-Stage COOL Speed
1 2 3 4 1 2 3 4 1 2 3 4
cfm cfm cfm cfm cfm cfm cfm cfm cfm cfm cfm cfm
+ 1450 1670 1880 2340 1050 1200 1340 1650 1440 1670 1950 2340
NORM 1340 1520 1730 2100 950 1200 1230 1520 1325 1530 1740 2150
- 1210 1390 1570 1915 850 1000 1100 1375 1200 1380 1600 1950
NOTES - The effect of static pressure, filter and electric heater resistance is included in the air volumes listed.
First-stage cooling air volume is approximately 70% of the second-stage COOL speed setting.........
Continuous fan speed is approximately 50% of second-stage COOL speed setting.........
Lennox Harmony III
®
Zone Control Applications - Minimum air handler speed is approximately 450 cfm.........
Table 8. CBX25UHV‐060 Air Handler Performance (0 through 0.80 in. w.g. External Static Pressure Range)
ADJUST
Jumper
Setting
BDC3 Jumper Speed Positions
HEAT Speed First-Stage COOL Speed Second-Stage COOL Speed
1 2 3 4 1 2 3 4 1 2 3 4
cfm cfm cfm cfm cfm cfm cfm cfm cfm cfm cfm cfm
+ 1700 1930 2120 2275 1225 1410 1530 1690 1720 1930 2140 2270
NORM 1570 1760 1925 2100 1120 1260 1400 1540 1580 1765 1970 2100
- 1420 1595 1760 1920 1015 1160 1275 1390 1430 1625 1780 1890
NOTES - The effect of static pressure, filter and electric heater resistance is included in the air volumes listed.
First-stage cooling air volume is approximately 70% of the second-stage COOL speed setting.........
Continuous fan speed is approximately 50% of second-stage COOL speed setting.........
Lennox Harmony III
®
Zone Control Applications - Minimum air handler speed is approximately 450 cfm.........
Table 9. CBX25UHV, Thermostat and Single-Stage Outdoor Unit Operating Sequence
Operating Sequence System Demand System Response
System
Condition
Step
Thermostat Demand Relative Humidity
Com
pressor
Air
Handler
CFM
(COOL)
Comments
Y1 Y2 O G W1 W2 Status D
NO CALL FOR DEHUMIDIFICATION
Normal
Operation
1 On On On Acceptable 24 VAC High 100%
Compressor and indoor
air handler follow thermo
stat demand.
BASIC MODE (only active on a Y1 thermostat demand)
Normal
Operation
1 On On On Acceptable 24 VAC High 100%
Thermostat energizes Y1
and de-energizes D on a
call for dehumidification.
Dehumidification
Call
2 On On On Demand 0 VAC High
60%/65
70%*
PRECISION MODE (operates independent of a Y1 thermostat demand)
Normal
Operation
1 On On On Acceptable 24 VAC High 100%
Dehumidification mode
begins when humidity is
greater than set point.
Dehumidification
call
2 On On On Demand 0 VAC High
60%/65%
70%*
Dehumidification
call ONLY
1 On On On Demand 0 VAC High
60%/65%
70%*
Thermostat will try to
maintain room humidity
setpoint by allowing the
room space to maintain a
cooler room thermostat
setpoint.**
Jumpers at indoor unit with a single stage outdoor unit
With Condensing unit - Y1 to Y2 and R to O
With Heat Pump - Y1 to Y2
* During dehumidification, cooling air handler speed is as follows: 70% of second-stage COOL cfm for 018, 024, 030, 65% for 036 and 60% for 042, 048 and
060 units.
** Thermostat will maintain the room temperature up to 2°F (1.2°C) cooler than the room thermostat setting in precision mode.
