ELECTRIC HEAT DATA - CBX32MV-036
SINGLE PHASE ELECTRIC HEAT
CBX32MV-036
Model Number
No. of
Stages
Volts
Input
kW
Input
1
Btuh In
put
2
Blower Mo
tor Full Load
Amps
3
Minimum Circuit
Ampacity
5
Maximum
Overcurrent
Protection
Circuit Circuit
1 2 1 2
4 kW
4 lbs.
ECB40−4 (55W89)
Terminal Block
ECB40−4CB (55W90)
35A Circuit breaker
1
208 3.0 10,250 4.0 23 - - - 25 - - -
220 3.4 11,450 4.0 24 - - - 25 - - -
230 3.7 12,550 4.0 25 - - - 25 - - -
240 4.0 13,650 4.0 26 - - - 30 - - -
5 kW
4 lbs.
ECB40−5 (34W87)
Terminal Block
ECB40−5CB (34W90)
35A Circuit breaker
1
208 3.8 12,800 4.0 28 - - - 30 - - -
220 4.2 14,300 4.0 29 - - - 30 - - -
230 4.6 15,700 4.0 30 - - - 30 - - -
240 5.0 17,100 4.0 31 - - - 35 - - -
6 kW
4 lbs.
ECB40−6 (34W88)
Terminal Block
ECB40−6CB (34W91)
40A Circuit breaker
1
208 4.5 15,400 4.0 32 - - - 35 - - -
220 5.0 17,100 4.0 33 - - - 35 - - -
230 5.5 18,800 4.0 35 - - - 35 - - -
240 6.0 20,500 4.0 36 - - - 40 - - -
8 kW
5 lbs.
ECB40−8 (34W89)
Terminal Block
ECB40−8CB (34W92)
50A Circuit breaker
1
208 6.0 20,500 4.0 41 - - - 45 - - -
220 6.7 22,900 4.0 43 - - - 45 - - -
230 7.3 25,100 4.0 45 - - - 45 - - -
240 8.0 27,300 4.0 47 - - - 50 - - -
9 kW
5 lbs.
ECB40−9CB (34W93)
60A Circuit breaker
2
208 6.8 23,100 4.0 46 - - - 50 - - -
220 7.6 25,800 4.0 48 - - - 50 - - -
230 8.3 28,200 4.0 50 - - - 50 - - -
240 9.0 30,700 4.0 52 - - - 60 - - -
12.5 kW
10 lbs.
ECB40−12.5CB (34W94)
(1) 30A & (1) 45A Circuit
breaker
2
208 9.4 32,000 4.0 24 38 25 40
220 10.5 35,800 4.0 25 40 25 40
230 11.5 39,200 4.0 26 42 30 45
240 12.5 42,600 4.0 27 44 30 45
15 kW
12 lbs.
ECB40−15CB (34W95)
(1) 35A & (1) 60A Circuit
breaker
2
208 11.3 38,400 4.0 28 45 30 45
220 12.6 43,000 4.0 29 48 30 50
230 13.8 47,000 4.0 30 50 30 50
240 15.0 51,200 4.0 31 52 35 60
20 kW
19 lbs.
ECB40−20CB (34W96)
(2) 60A Circuit breaker
2
208 15.0 51,200 4.0 46 50 50 50
220 16.8 57,300 4.0 48 53 50 60
230 18.4 62,700 4.0 50 55 50 60
240 20.0 68,200 4.0 52 57 60 60
THREE PHASE ELECTRIC HEAT
8 kW
5 lbs.
ECB40−8 (34W98)
Terminal Block
1
208 6.0 20,500 4.0 26 - - - 30 - - -
220 6.7 22,900 4.0 27 - - - 30 - - -
230 7.3 25,100 4.0 28 - - - 30 - - -
240 8.0 27,300 4.0 28 - - - 30 - - -
10 kW
6 lbs.
ECB40−10 (34W99)
Terminal Block
1
208 7.5 25,600 4.0 31 - - - 35 - - -
220 8.4 28,700 4.0 33 - - - 35 - - -
230 9.2 31,400 4.0 34 - - - 35 - - -
240 10.0 34,100 4.0 35 - - - 35 - - -
15 kW
12 lbs.
ECB40−15CB (35W00)
50A Circuit breaker
1
208 11.3 38,400 4.0 44 - - - 45 - - -
220 12.6 43,000 4.0 46 - - - 50 - - -
230 13.5 47,000 4.0 48 - - - 50 - - -
240 15.0 51,200 4.0 50 - - - 50 - - -
