CBX32MV
CBX32MV‐068 BLOWER MOTOR WATTS AT NORM SETTING (Adjust Jumper at NORM Setting)
Jumper Speed Positions
Motor Watts @ Various External Static Pressures - in. wg. (Pa)
0 (0) 0.1 (25) 0.2 (50) 0.3 (75) 0.4 (100) 0.5 (125) 0.6 (150) 0.7 (175) 0.8 (200)
HEAT Speed
Tap 1 310 345 385 425 465 510 560 610 665
Tap 2 345 385 420 460 500 620 615 680 735
Tap 3 385 430 480 525 580 640 695 750 815
Tap 4 475 525 560 615 660 720 785 845 810
COOL Speed
Tap 1 180 205 240 285 325 365 405 435 480
Tap 2 250 285 320 355 410 455 505 535 585
Tap 3 345 375 415 460 505 560 610 670 735
Tap 4 445 510 560 595 665 725 790 845 865
CBX32MV‐068 BLOWER MOTOR WATTS AT - (Minus) SETTING (Adjust Jumper at - Setting)
Jumper Speed Positions
Motor Watts @ Various External Static Pressures - in. wg. (Pa)
0 (0) 0.1 (25) 0.2 (50) 0.3 (75) 0.4 (100) 0.5 (125) 0.6 (150) 0.7 (175) 0.8 (200)
HEAT Speed
Tap 1 215 245 285 325 375 415 460 495 540
Tap 2 255 295 325 370 410 460 510 545 580
Tap 3 295 330 375 395 445 495 555 600 660
Tap 4 335 370 400 445 505 550 600 660 705
COOL Speed
Tap 1 125 150 170 210 245 270 300 340 370
Tap 2 160 185 225 255 300 335 365 415 450
Tap 3 225 245 280 320 370 420 460 510 545
Tap 4 290 325 355 400 445 490 545 595 650
