DC60-DM60-ROOFTOP-IOM-1310-E - 9 -
1.6.3 Alarms code
This item allows you to view the code of different active alarms on the Unit.
If the Unit isn't in alarm, this item is to 0.
1.6.4
Indoor (Room) temperature
This item indicates the measured air temperature in the room conditioning.
The room temperature isn't available if the Climatic™60 is configured to supply control.
1.7 DC60 set in ‘Full’ mode
- : Unit Index selected by the ‘DC60’
- *: On/Off of the Unit selected.
- : Predetermined temperature set point current mode (°C)
- : Volatile temperature set point current mode (°C)
- : Alarms code
-
* : Outdoor temperature (°C)
- : Supply temperature (°C)
-
* : Indoor (Room) temperature (°C)
- * : Indoor (Room) humidity (%hr)
- * : Indoor (Room) Air quality (ppm)
- * : Opening of fresh air damper (%)
* : Available if the option is enabled.
: Available if the level 2 is activated.
: Adjustable with ‘DC60.
1.7.1
Unit connected
This item can select or know the Unit Index selected by the 'DC60'.
1.7.2
On/Off, Power
If the DC60 is used with the Master/Slaves bus this item allows you to view and/or change the status of starting or
stopping of the Unit selected.
1.7.3
Volatile Temperature set point
This item allows you to view and/or modify the control temperature required for the Unit selected.
If this point is changed, this value is used until the scheduling changes mode (A, B, C, D, BMS).
At each change of the mode, the Climatic™60 sets the value of this set point on the preset value in the mode
concerned.
1.7.4
Predetermined Temperature set point
If level 2 is active, this item allows you to view and/or change the preset temperature control for the active mode.
