Lennox EDVSTNM-B User Manual

12
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
12 (305)
10
(254)
TOP VIEW
40-1/8
(1019)
3-1/2
(89)
5/8
(16)
Stepped to Accept Drywall on Two Corners
FRAMING SPACERS
(Top and Side)
FINISH WALL BRACKET
(Front, back, and left edge of unit top)
6-7/8
(175)
10-1/4
(260)
12
(305)
(63.5)
RIGHT SIDE VIEW
LEFT SIDE VIEW
3 (76)
1/2
(13)
DETAIL OF
FINISH WALL BRACKET
FLUE
(Top or Side)
2-1/2
(63.5)
2-1/2
NOTE - Unit has a factory-installed vent seal
cap and vent cover plate (see Figures 22 and
23 on page 15) in each flue outlet. The vent
seal cap is not shown in this figure.
Provide Additional
Space For Side
Vent Seal Cap If
Installing Against
A Solid Wall
24
(610)
41
(1041)
37
(940)
43-5/8
(1108)
1/2 (13)
FRONT VIEW
4 (102)
GAS INLET
ELECTRICAL
INLETS
CONTROL COMPARTMENT
ACCESS PANEL
EDVPF (Peninsula)
Figure 18
EDVST (See-Through)
41
(1041)
37
(940)
47-1/8
(1197)
6-7/8
(175)
10-1/4
(260)
12
(305)
12 (305)
10
(254)
(63.5)
FRONT VIEW
RIGHT SIDE VIEW
LEFT SIDE VIEW
TOP VIEW
3 (76)
4 (102)
FLUE
(Top or Side)
10-1/2
(267)
1/2 (13)
FLUE
(Top or Side)
GAS INLET
ELECTRICAL
INLETS
GAS INLET
40-1/8
(1019)
5/8
(16)
Stepped to Accept Drywall
on All 4 Corners
3-1/2 (89)
3 (76)
ELECTRICAL
INLETS
FRAMING SPACERS
(Top and Both Sides)
24
(610)
CONTROL
COMPARTMENT
ACCESS PANEL
FINISH WALL BRACKET
(Front and back edge of unit top)
1/2
(13)
DETAIL OF
FINISH WALL BRACKET
1/2 (13)
2-1/2
(63.5)
2-1/2
ELECTRICAL
INLETS
NOTE - Unit has a factory-installed vent seal
cap and vent cover plate (see Figures 22 and
23 on page 15) in each flue outlet. The vent
seal cap is not shown in this figure.
3-1/2 (89)
Provide Additional
Space For Side
Vent Seal Cap If
Installing Against
A Solid Wall
Figure 17
FIREPLACE SPECIFICATIONS

Lennox EDVSTNM-B Specifications

General

Brand	Lennox
Model	EDVSTNM-B
Category	Indoor Fireplace
Language	English
