Lennox EL180UH080NE48B

Page 5
FIGURE 1
Control Box
(includes integrated control,
interlock switch and transformer)
Blower Assembly
Power Choke
(4 and 5 Ton Only)
PARTS ARRANGEMENT
Heat Exchanger
Combustion Air Inducer
Gas Valve
Intake Air Elbow
Access Panel
Inner Access
Panel
Intake Screen
