Lennox EL196UH110XE60C

Page 2
SPECIFICATIONS
Gas
Heating
Performance
Model No. EL196UH030XE24B EL196UH045XE24B EL196UH045XE36B
1
AFUE 96% 96% 96%
Input - Btuh 30,000 44,000 44,000
Output - Btuh 29,000 42,000 42,000
Temperature rise range - °F 30 - 60 40 - 70 35 - 65
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10 3.5 / 10 3.5 / 10
High static - in. w.g. 0.5 0.5 0.5
Energy Star® Certied Yes Yes Yes
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nom. dia. x width - in. 10 x 8 10 x 8 10 x 8
Motor Type DC Brushless DC Brushless DC Brushless
Motor output - hp 1/2 1/2 1/2
Tons of add-on cooling 1 - 2 1 - 2 1.5 - 3
Air Volume Range - cfm 260 - 990 260 - 990 520 - 1345
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 6.8 6.8 6.8
Maximum overcurrent protection 15 15 15
Shipping Data lbs. - 1 package 129 129 129
SPECIFICATIONS
Gas
Heating
Performance
Model No. EL196UH070XE36B EL196UH090XE48C EL196UH110XE60C
1
AFUE 96% 96% 96%
Input - Btuh 66,000 88,000 110,000
Output - Btuh 63,000 85,000 106,000
Temperature rise range - °F 35 - 65 50 - 80 45 - 75
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10 3.5 / 10 3.5 / 10
High static - in. w.g. 0.5 0.5 0.5
Energy Star® Certied Yes Yes Yes
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nom. dia. x width - in. 10 x 8 10 x 10 11-1/2 x 10
Motor Type DC Brushless DC Brushless DC Brushless
Motor output - hp 1/2 3/4 1
Tons of add-on cooling 1.5 - 3 2.5 - 4 3 - 5
Air Volume Range - cfm 550 - 1380 760 - 1740 1055 - 2220
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 6.8 8.4 10.9
Maximum overcurrent protection 15 15 15
Shipping Data lbs. - 1 package 134 158 170
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization Efciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized furnaces.
