SPECIFICATIONS
Gas
Heating
Performance
Model No. EL296UH045XE36B EL296UH070XE36B EL296UH090XE48C
1
AFUE 96% 95.5% 95.7%
High
Fire
Input - Btuh 44,000 66,000 88,000
Output - Btuh 43,000 64,000 85,000
Temperature rise range - °F 35-65 50-80 45-75
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0 3.5 / 10.0
Low
Fire
Input - Btuh 29,000 43,000 57,000
Output - Btuh 28,000 42,000 55,000
Temperature rise range - °F 20 - 50 25 - 55 30 - 60
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
1.7 / 4.9 1.7 / 4.9 1.7 / 4.9
High static - in. w.g. Heating 0.5 0.5 0.5
Cooling 0.5 0.5 0.5
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nominal diameter x width - in. 10 x 8 10 x 8 10 x 10
Motor output - hp 1/2 1/2 3/4
Tons of add-on cooling 1.5 - 3 1.5 - 3 2.5 - 4
Air Volume Range - cfm 520 - 1345 550 - 1380 760 - 1740
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 6.8 6.8 8.4
Maximum overcurrent protection 15 15 15
Shipping Data lbs. - 1 package 129 137 161
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization Efciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized
furnaces.
SPECIFICATIONS
Gas
Heating
Performance
Model No. EL296UH110XE60C EL296UH135XE60D
1
AFUE 96% 96%
High
Fire
Input - Btuh 110,000 132,000
Output - Btuh 106,000 127,000
Temperature rise range - °F 45-75 55-85
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0
Low
Fire
Input - Btuh 72,000 86,000
Output - Btuh 70,000 84,000
Temperature rise range - °F 35 - 65 40 - 70
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
1.7 / 4.9 1.7 / 4.9
High static - in. w.g. Heating 0.5 0.5
Cooling 0.5 0.5
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nominal diameter x width - in. 11-1/2 x 10 11-1/2 x 10
Motor output - hp 1 1
Tons of add-on cooling 3 - 5 3.5 - 5
Air Volume Range - cfm 1055 - 2220 1260 - 2405
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 10.9 10.9
Maximum overcurrent protection 15 15
Shipping Data lbs. - 1 package 174 189
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization Efciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized
furnaces.
