Page 6
FIGURE 1
EL296UHE PARTS IDENTIFICATION
Burner Box Assembly
Gas Valve
Heat Exchanger
Combustion
Air Inducer
Pressure
Switch
Assembly
Primary Limit
Constant Torque Indoor Blower Motor
Two-Stage Integrated Control
Outer Access Panel
Inner Access Panel
Bag Assemblies
(shipping location)
Field Make Up Box
Door
Interlock
Switch
