Page 2
EL297DFV Parts Identication
BURNERS
BLOWER
MOTOR
GAS VALVE
AND MANIFOLD
COMBUSTION AIR
INDUCER
FLUE
COLLAR
TOP CAP
INTEGRATED
CONTROL
PRESSURE SWITCH
ASSEMBLY
AIR INTAKE COLLAR
FIGURE 1
NOTE - This manual is the property of the homeowner
and must be left with the equipment user.
Notice to Homeowner
This furnace is equipped with safety devices that protect
you and your property. If one or more of these devices is
activated, furnace operation will stop.
If your home is left unattended for an extended period of
time, equipment operation must be checked periodically.
If this is not possible, the water supply to the house should
be shut o and the pipes should be drained. This will pre-
vent problems associated with a NO HEAT condition (fro-
zen pipes, etc
