SPECIFICATIONS
Gas
Heating
Performance
Model No. EL297UH045XV36B EL297UH070XV36B EL297UH090XV36C
1
AFUE 97% 97% 97%
High
Fire
Input - Btuh 44,000 66,000 88,000
Output - Btuh 43,000 64,000 85,000
Temperature rise range - °F 35 - 65 50 - 80 60 - 90
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0 3.5 / 10.0
Low
Fire
Input - Btuh 29,000 43,000 57,000
Output - Btuh 28,000 42,000 56,000
Temperature rise range - °F 20 - 50 25 - 55 30 - 60
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
1.7 / 4.5 1.7 / 4.5 1.7 / 4.5
High static - in. w.g. Heating 0.8 0.8 0.8
Cooling 1.0 1.0 1.0
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nominal diameter x width - in. 10 x 9 10 x 9 10 x 9
Motor output - hp 1/2 1/2 1/2
Tons of add-on cooling 2 - 3 2 - 3 2 - 3
Air Volume Range - cfm 465 - 1370 490 - 1365 520 - 1360
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 7.7 7.7 7.7
Maximum overcurrent protection 15 15 15
Shipping Data lbs. - 1 package 130 136 152
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization E󰀩ciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized
furnaces.
SPECIFICATIONS
Gas
Heating
Performance
Model No. EL297UH090XV48C EL297UH090XV60C EL297UH110XV48C
AHRI Ref. No. 4988513 4988514 4988515
1
AFUE 97% 97% 97%
High
Fire
Input - Btuh 88,000 88,000 110,000
Output - Btuh 86,000 86,000 106,000
Temperature rise range - °F 45 - 75 40 - 70 60 - 90
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0 3.5 / 10.0
Low
Fire
Input - Btuh 57,000 57,000 72,000
Output - Btuh 56,000 56,000 70,000
Temperature rise range - °F 30 - 60 25 - 55 35 - 65
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
1.7 / 4.5 1.7 / 4.5 1.7 / 4.5
High static - in. w.g. Heating 0.8 0.8 0.8
Cooling 1.0 1.0 1.0
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nominal diameter x width - in. 11 x 11 11 x 11 11 x 11
Motor output - hp 3/4 1 3/4
Tons of add-on cooling 2.5 - 4 3 - 5 2.5 - 4
Air Volume Range - cfm 680 - 1770 840 - 2195 670 - 1760
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 10.1 12.8 10.1
Maximum overcurrent protection 15 20 15
Shipping Data lbs. - 1 package 163 164 173
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization E󰀩ciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized
furnaces.
