Page 15
Communicating
Indoor Unit
S30 Smart Hub
C
i+
i-
R
HD Display
Subbase or
Mag-Mount
-
COMMBUS
A B
ACC1 ACC2
EL18XPV
Outdoor Unit
EL18XPV
RAST 6-Pin
Connectors
OATS (Optional)
DATS (Optional)
+
B
A
+
-
TST
DS
O
Y1
Y2
L
W
DF
Indoor Control
Single Wire To
C Terminal
Unused Wires
Unused Wires
Single Wire To C Terminal
PROVIDED RAST
6-PIN CONNECTOR
INDOOR CONTROL
FIGURE 13. EL18XPV with iComfort S30 Communicating Thermostat – Field Wiring Diagram

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lennox Elite EL18XPV Series and is the answer not in the manual?

Lennox Elite EL18XPV Series Specifications

General IconGeneral
Compressor TypeVariable Speed
RefrigerantR-410A
Energy Star CertifiedYes
StagesVariable
ClimateAll Climates
HSPF10
Smart TechnologyiComfort-enabled technology
Warranty10-Year Limited Warranty on covered components
SEERUp to 18
