Lennox ELS SERIES User Manual

Page 21
TABLE 8. Normal Operating Temperatures – Residential Matchups
ELS120S4D + (2) CBA27UHE-060 or
(2) CBA38MV-060
ELS120S4D + (2) CH33-62D ELS120S4D + (2) CH23-068
Normal Operating Pressures Normal Operating Pressures Normal Operating Pressures
STAGE 1
(ºF)
Liquid at
ODSV
Suction
STAGE 1
(ºF)
Liquid at
ODSV
Suction
STAGE 1
(ºF)
Liquid at
ODSV
Suction
65 251 133 65 240 125 65 241 128
75 292 135 75 280 129 75 281 131
85 340 137 85 324 132 85 325 134
95 391 140 95 372 135 95 373 137
105 446 143 105 425 139 105 427 141
115 505 145 115 483 143 115 484 144
125 569 148 125 545 146 125 547 147
STAGE 2
65 250 131
STAGE 2
65 241 125
STAGE 2
65 242 128
75 287 134 75 282 128 75 283 131
85 333 136 85 326 131 85 326 133
95 384 139 95 374 134 95 375 136
105 441 142 105 427 137 105 428 139
115 501 144 115 484 141 115 486 142
125 566 147 125 548 145 125 550 146
Normal Operating Temperatures – Residential Matchups
ELS120S4D + (2) CX35-60C ELS120S4D + (2) CX35-60D
Normal Operating Pressures Normal Operating Pressures
STAGE 1
(ºF)
Liquid at
ODSV
Suction
STAGE 1
(ºF)
Liquid at
ODSV
Suction
65 241 130 65 240 127
75 282 133 75 281 130
85 326 136 85 325 134
95 374 139 95 373 137
105 427 142 105 427 141
115 485 145 115 484 145
125 548 148 125 548 148
STAGE 2
65 243 129
STAGE 2
65 241 127
75 282 132 75 282 130
85 327 135 85 327 133
95 375 138 95 374 136
105 428 141 105 428 139
115 486 144 115 486 143
125 550 147 125 550 146
