Page 22
V-MAINTENANCE
Installation and service must be performed by a licensed
professional installer (or equivalent) or a service agen-
cy. At the beginning of each cooling season, the system
should be checked as follows:
WARNING
Electric Shock Hazard. Can cause injury or
death. Unit must be properly grounded in
accordance with national and local codes.
Line voltage is present at all components
when unit is not in operation on units with
single-pole contactors. Disconnect all remote
electric power supplies before opening
access panel. Unit may have multiple power
supplies.
OUTDOOR UNIT
1 - Clean and inspect outdoor coil (may be ushed with
a water hose). Ensure power is off before cleaning.
2 - Outdoor unit fan motor is pre-lubricated and sealed.
No further lubrication is needed.
3 - Visually inspect all connecting lines, joints and coils
for evidence of oil leaks.
4 - Check all wiring for loose connections.
5 - Check for correct voltage at unit (unit operating).
6 - Check amp draw on outdoor fan motor.
UNIT NAMEPLATE: _________ ACTUAL: __________
NOTE – If insufcient heating or cooling occurs, the
unit should be gauged and refrigerant charge should be
checked.
INDOOR COIL
1 - Clean coil if necessary.
2 - Check connecting lines, joints and coil for evidence
of oil leaks.
3 - Check condensate line and clean if necessary.
INDOOR UNIT
1 - Clean or change lters.
2 - Blower motors are prelubricated and permanently
sealed. No more lubrication is needed.
3 - Adjust blower speed for cooling. Measure the
pressure drop over the coil to determine the correct
blower CFM. Refer to the unit information service
manual for pressure drop tables and procedure.
4 - Belt Drive Blowers - Check belt for wear and proper
tension.
5 - Check all wiring for loose connections.
6 - Check for correct voltage at unit. (blower operating)
7 - Check amp draw on blower motor.
UNIT NAMEPLATE: _________ ACTUAL: __________
