BLOWER DATA
G61MPV−60C−091 BLOWER PERFORMANCE (less filter)
Bottom Return Air, Return Air from Both Sides or Return Air from Bottom and One Side.
0 through 1.00 in. w.g. External Static Pressure Range
ADJUST"
Switch
Positions
Speed Switch Positions
Second Stage HEAT" Speed − cfm Second Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1560 1770 1895 2110 1665 1790 1990 2175
1
NORM 1400 1575 1745 1930 1515 1625 1815 2020
 1245 1400 1565 1745 1340 1445 1645 1800
ADJUST"
Switch
Positions
First Stage HEAT" Speed − cfm First Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1420 1625 1780 1965 1240 1245 1410 1585
1
NORM 1280 1465 1615 1790 1060 1125 1270 1430
 1145 1290 1445 1610 940 1015 1145 1270
1
Factory default jumper setting.
N/A − First and second stage HEAT positions shown cannot be used on this model.
NOTES − The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage
HEAT speed position.
First stage COOL (two−stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position − minimum 500 cfm.
Lennox Harmony IIIt Zone Control Applications − Minimum blower speed is 458 cfm.
G61MPV−60C−091 BLOWER MOTOR WATTS
Jumper Speed
Positions
Motor Watts @ Various External Static Pressures − in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
+" (Plus) SETTING (Adjust" Jumper at +" Setting)
HEAT"
Speed
Tap 1 255 280 305 330 355 390 420 450 475 305 340 375 415 450 475 505 530 560
Tap 2 325 360 390 425 460 500 540 580 615 395 440 490 540 585 620 655 690 730
Tap 3 495 525 555 590 620 650 680 710 710 615 645 675 705 740 755 775 790 765
Tap 4 625 660 700 740 780 815 855 890 890 800 840 880 920 960 985 1005 1030 1000
COOL"
Speed
Tap 1 180 200 225 250 280 300 320 345 370 390 420 455 485 520 550 585 615 640
Tap 2 200 225 250 280 305 330 350 375 395 485 520 555 590 625 655 680 710 735
Tap 3 245 270 300 335 365 390 420 445 470 655 700 740 785 830 860 890 925 930
Tap 4 355 380 405 435 465 495 520 550 585 930 960 990 1020 1050 1060 1070 1045 1005
NORM" (Normal) SETTING (Adjust" Jumper at NORM" Setting)
HEAT"
Speed
Tap 1 185 210 235 265 290 315 340 365 390 230 260 290 320 350 375 405 430 460
Tap 2 240 270 305 340 375 410 445 475 505 300 335 370 410 450 485 520 560 595
Tap 3 385 410 435 455 480 510 540 656 595 465 495 530 565 595 625 650 680 690
Tap 4 480 510 540 570 600 605 670 705 740 585 626 670 710 750 785 820 855 870
COOL"
Speed
Tap 1 110 130 155 180 205 230 250 275 295 285 315 350 380 415 440 465 490 525
Tap 2 140 160 185 205 230 250 265 285 310 345 380 420 460 495 525 550 580 615
Tap 3 185 210 235 265 290 320 350 380 395 485 525 565 610 650 680 715 745 775
Tap 4 245 275 305 335 365 395 420 450 480 680 720 765 810 855 885 910 940 960
−" (Minus) SETTING (Adjust" Jumper at −" Setting)
HEAT"
Speed
Tap 1 145 165 190 210 235 255 280 300 320 175 195 225 250 275 295 320 340 365
Tap 2 175 200 225 255 280 305 335 360 385 220 250 280 315 350 375 400 430 460
Tap 3 275 305 330 360 385 410 435 460 485 365 390 410 435 460 485 510 535 555
Tap 4 340 370 405 440 475 505 535 570 600 460 490 520 550 580 610 640 675 700
COOL"
Speed
Tap 1 90 105 125 145 165 185 205 225 245 215 240 270 300 325 350 375 395 425
Tap 2 105 125 150 170 195 215 235 255 270 255 285 315 345 380 405 430 455 495
Tap 3 145 165 190 215 235 260 280 305 325 385 410 440 470 495 535 570 605 630
Tap 4 190 215 240 265 290 315 345 370 395 485 520 555 590 625 660 700 735 765
