Page 3
G71MPP Parts Arrangement
FIGURE 1
BURNER BOX ASSEMBLY
HEAT EXCHANGER
WARM HEADER
(COLLECTOR BOX)
COLD HEADER
(COLLECTOR BOX)
COMBUSTION AIR
PRESSURE
SWITCHES
CONDENSER COIL
BURNER ACCESS PANEL
BLOWER ACCESS PANEL
SIGHT GLASS
VARIABLE SPEED
COMBUSTION AIR INDUCER
VARIABLE SPEED
BLOWER MOTOR
INTEGRATED
CONTROL
ELBOW
(shipping location)
TRANSFORMER
BAG ASSEMBLIES
(shipping location)
VARIABLE CAPACITY
GAS VALVE
SHIPPING BLOCK
(−135 units only)
PRESSURE SWITCH
ASSEMBLY WITH
PRESSURE
CONDITIONING
DEVICE
