Lennox GCS16-1853-235 User Manual

Page 26
COMBUSTION AIR BLOWER
COMBUSTION AIR
BLOWER CAPACITOR C3
COMBUSTION AIR
BLOWER MOTOR B6
GAS VALVE
GAS MANIFOLD
HEATING CONTROLS BOX
OR
CONTROLS HAT SECTION
SPARK ELECTRODE
(hidden from view)
FLAME SENSOR
ELECTRODE
HEAT EXCHANGE
TUBES
BURNERS
AIR BAFFLE
PROVE SWITCH S18
(outer portion of motor housing)
FIGURE 15
FLAME ROLLOUT
SWITCH S47
ROLLOUT SWITCH
MOUNTING BRACKET
TYPICAL HEAT EXCHANGER ASSEMBLY
UNITS EQUIPPED WITH SINGLE HEAT EXCHANGER
FIGURE 16
TYPICAL HEAT EXCHANGER ASSEMBLY
UNITS EQUIPPED WITH DUAL HEAT EXCHANGERS
HEAT EXCHANGE
TUBES
AIR BAFFLE
GAS VALVE GV1
GAS MANIFOLD
BURNERS
COMBUSTION AIR
BLOWER B6
COMBUSTION AIR
BLOWER B15
GAS
VALVE
GV3
HEATING
CONTROL BOX
FIRST STAGE
HEATING
SECTION
SECOND STAGE
HEATING
SECTION
PROVE SWITCH S18
(outer portion of motor housing)
PROVE SWITCH S18
(outer portion of motor housing)
FLAME ROLLOUT
SWITCH S47
ROLLOUT SWITCH
MOUNTING BRACKET
SPARK ELECTRODE
(hidden from view)
SPARK ELECTRODE
(hidden from view)
FLAME
SENSOR
ELECTRODE
FLAME
SENSOR
ELECTRODE
