Management of 0-10V Input
P78=1 P78 = 2
0-10V DC Electrical Signal Input Heating Flow Setpoint Temperature GCWB9W-150 GCWB9W-205
(V) (°F) (°C) (kW) (Btu/h) (kW) (Btu/h)
0...3 OFF
3 77 25 6.4 22,000 8.6 29,500
4 95 35 10.8 36,700 14.2 48,620
5 108 42 15.1 51,400 19.9 67,740
6 124 51 19.4 66,100 25.5 86,860
7 140 60 23.7 80,800 31.1 105,980
8 154 68 28.0 95,500 36.7 125,100
9 167 75 32.3 110,200 42.3 144,220
10 176 80 36.6 125,000 48.1 164,000
The functions with 0...10V regulator are activated by means of their parameters. When the function is enabled
(P82=3) and P78=1, the input manages the heating set point temperature directly; when P78=2, the input
manages the heating power input directly. Demand is activated above 3V and the heating setpoint is calculated in
proportion to deviation from 3 to 10 V DC, to give a setpoint that goes from minimum to maximum.
PN 240012998 REV A [04/15/2020]
