7
PIPING LEGEND
ZONE VALVE
BALL VALVE
AIR SEPERATOR
CIRCULATOR
DRAIN
COMBINATION FILL
FLOW CHECK VALVE
BYPASS VALVE
DIVERTER VALVE
T&P OR RELIEF VALVE
THERMOSTATIC MIXING VALVE
TEMPERATURE & PRESSURE GAUGE
EXPANSION TANK
FLAT PLATE HEAT EXCHANGER
(COMBI ONLY)
STRAINER
PIPING LEGEND
PURGE VALVE
MAGNETIC DIRT SEPARATOR
PN 240012998 REV A [04/15/2020]
