JACKET AND BASE ASSEMBLY
KEY # DESCRIPTION QUANTITY
ITEM
NUMBER
1 FRONT PANEL 1 750001020
2 RIGHT PANEL 1 750001021
3 LEFT PANEL 1 750001022
4 BACK PANEL 1 750001023
5 TOP PANEL 1 750001024
6 BASE 1 750001025
7 CONTROL PANEL 1 650001026
8 AT140B1016 TRANSFORMER 24 VAC 1 550001339
9 - - - - - - - - - - - -
10 UT 1013-10 INTEGRATED BOILER CONTROL 1 14662803
11 CO-2366 GLIDE 4 14631091
12 HEYCO OCB-1500 BUSHING 1 14631120
13 RACO 232 4´4´2 BOX 1 14631316
14 - - - - - - - - - - - -
15 P&S SWITCH 691-I 1 14631319
16 COVER PLATE RACO 902-802 1 14631318
17 419-1AA1 2½” PLUG 2 14631174
18 415-1AA1 1½” PLUG 2 14631171
19 BPF 3 ½” PLUG 1 14631176
20 421-1AA1 3” PLUG 2 14631175
21 LOWER FRONT PANEL 1 750001027
22 DOOR PULLS 2 CI-001.03
‡ TACO CIRCULATING PUMP 1 750001027
‡ TACO ISOLATION VALVE SET 1 14626048
‡ GRUNDFOS CIRCULATING PUMP 1 14626045
‡ GRUNDFOS ISOLATION VALVE SET 1 14626046
‡ CIRCULATING PUMP HARNESS 1 43300826
‡ WIRING HARNESS 1 14631315
‡ JACKET COMPLETE - - - - 750001002
‡
3” CONCENTRIC VENT KIT ULC S636 1 240007554
‡ - Not Shown

