Lennox HSXA12-018 User Manual

Page 2
Unit Dimensions − inches (mm)
Side View
ELECTRICAL
INLETS
VAPOR &
LIQUID LINE
CONNECTION
INLET
AIR
INLET
AIR
DISCHARGE AIR
Side View
Top View
A
B
OUTDOOR
COIL FAN
COMPRESSOR
INLET AIR
INLET AIR
VAPOR LINE
CONNECTION
2-3/4 (70)
LIQUID LINE
CONNECTION
OPTIONAL UNIT
STAND-OFF KIT (4)
(Field Installed)
4-3/8
(111)
6-3/8
(162)
6-3/8
(162)
Top View Base Section
2 (51)
3/4
(19)
4-3/8
(111)
4-3/8
(111)
4-3/8
(111)
4-3/8
(111)
4-3/8
(111)
COMPRESSOR
COIL DRAIN OUTLETS
(Around perimeter of base)
OPTIONAL UNIT
STAND-OFF KIT (4)
(Field Installed)
C
C
Model No. A B C
HSXA12-018
in. 25 24-1/4 24-1/4
HSXA12
-
018
HSXA12-024
mm 635 616 616
HSXA12-030
HSXA12-036
in. 33 32-1/4 24-1/4
HSXA12-036
HSXA12-042
HSXA12-048
mm 838 819 616
HSXA12 060
in. 29 28−1/4 28−1/4
HSXA12-060
mm 737 718 718
