• 14 •
Installation, operation and maintenance / INALTO-IOM-1809-E
SUPPLY GRILL ON PAM ASSEMBLY DIAGRAM
Size 05 to 28
x6 Self-drilling screw TC+4,2x13 UNI8118
Sizes 49 & 57
x8 Self-drilling screw TC+4,2x13 UNI8118
SUPPLY GRILL ON RAM ASSEMBLY DIAGRAM
Size 05 to 28
x6 Self-drilling screw TC+4,2x13 UNI8118
Sizes 49 & 57
x8 Self-drilling screw TC+4,2x13 UNI8118
Pic. 21
Pic. 22
ASSEMBLY DIAGRAMS
