• 13 •
Installation, operation and maintenance / INALTO-IOM-1809-E
Size 05 to 28
x8 Screw TC+M5x12 UNI7687
x8 Hex nut M5 fl anged with corrugated washer DIN4161
Sizes 49 & 57
x10 Screw TC+M5x12 UNI7687
x10 Hex nut M5 fl anged with corrugated washer DIN4161
Size 05 to 28
x8 Screw TC+M5x12 UNI7687
x8 Hex nut M5 fl anged with corrugated washer DIN4161
Sizes 49 & 57
x10 Screw TC+M5x12 UNI7687
x10 Hex nut M5 fl anged with corrugated washer DIN4161
ASSEMBLY DIAGRAMS
Figure 19
Figure 20
BAM ON PAN
BAM ON RAM
