• 17 •
PE
Com
I
II
III
C1
M1
XA1
Installation, operation and maintenance / INALTO-IOM-1809-E
Size 05 to 15
LEGEND:
Earth (yellow/green)
Common
Minimum speed
Medium speed
Maximum speed
Capacitor
Motor
Electric box with terminal board for fan speed control M1
Pic. 29
Fan speed control
230V AC / 50 Hz
Cross section area = 1,5 mmq
C1
PE
XA1
3-SPEED MOTOR
WIRING DIAGRAMS
